Product Description
The IC695TBB132 is a 36-point, extended-depth terminal block designed for PACSystems RX3i IC695-series I/O modules. Engineered for industrial field wiring, it provides secure screw-type connections and an extra-deep shroud to accommodate thicker AC wiring and large cable bundles.
Functionally equivalent to the standard IC695TBB032, the IC695TBB132 adds 13 mm of depth to improve strain relief, simplify cable routing, and support high-density wiring in compact control panels. This terminal block supports both solid and stranded conductors (#14–26 AWG) and features a 7 in-lb torque rating for reliable connections under industrial vibration conditions.
Technical Specifications
Mechanical & Wiring
-
Terminal Type: Screw-type, box-style
-
Number of Terminals: 36
-
Wire Gauge Supported: #14–26 AWG (solid or stranded)
-
Wire Strip Length: 0.310 in (7.87 mm)
-
Torque Rating: 7 in-lb (0.79 N·m)
-
Extended Depth: +13 mm (0.5 in) compared to standard models
-
Purpose of Extended Depth: Supports thicker AC wiring and large bundles
-
Dimensions: 6 × 6 × 1.3 in (152 × 152 × 33 mm)
-
Weight: 3 lbs
Compatibility
-
PACSystems RX3i IC695-series high-density I/O modules
-
Series 90‑30 equivalent modules
-
Supports discrete, analog, and specialty 36-point modules
Environmental Ratings
-
Operating Temperature: 0 °C to 60 °C
-
Storage Temperature: –40 °C to +85 °C
-
Humidity: 5–95% non-condensing
Functional Features
-
36 individually accessible screw terminals for field wiring
-
Extra-deep shroud reduces stress on wires and improves cable management
-
Designed for high-density AC and I/O wiring
-
Secure clamping under vibration
-
Easy installation and removal without disturbing module electronics
Key Features
-
Extended-depth terminal block with 36 screw terminals
-
13 mm additional depth for thick insulation and large wire bundles
-
Supports #14–26 AWG solid or stranded wires
-
7 in-lb torque for reliable connections
-
Ideal for high-density PACSystems RX3i IC695-series modules
-
Durable industrial-grade construction
Applications
Suitable for industrial control panels, motor control centers, process automation wiring, and high-density AC I/O module installations where space is limited.
FAQ
Q: How does IC695TBB132 differ from IC695TBB032?
A: The TBB132 adds 13 mm of depth to improve strain relief and manage thicker wires while remaining functionally identical.
Q: Can it support stranded wires?
A: Yes, both solid and stranded wires from #14–26 AWG are supported.
Q: Is it compatible with older Series 90‑30 modules?
A: Yes, it works with high-density Series 90‑30 modules without modifications.
Q: Can it handle industrial vibration?
A: Yes, screw-type terminals maintain secure clamping under vibration.
