Product Overview
The IC695PNC001 PROFINET Controller Module by GE Fanuc enables high-speed industrial communication for PACSystems™ RX3i CPUs. It supports CPU315 or CPU320 with firmware version 7.0 or higher, offering seamless data exchange across PROFINET networks. The module features two RJ-45 ports and two SFP slots, sharing a single IP address for simplified network management.
This controller supports up to four modules per rack and connects with 64 I/O devices per unit or 128 across eight controllers. It accommodates ring, star, and daisy-chain topologies, with configurable update rates from 1 ms to 512 ms. The IC695PNC001 draws up to 1.5A at 5.5VDC and supports RIUP (removal/insertion under power) for uninterrupted operation.
Technical Specifications
| Parameter |
Specification |
| Model Number |
IC695PNC001 |
| Manufacturer |
GE Fanuc |
| Module Type |
PROFINET Controller Module |
| Product Series |
PACSystems™ RX3i |
| CPU Compatibility |
CPU315 / CPU320 (v7.0+) |
| Ports |
2 RJ-45, 2 SFP slots |
| IP Addressing |
Single IP for all ports |
| Max I/O Devices |
64 per controller / 128 total |
| Network Topologies |
Ring, Star, Daisy-chain |
| Update Rate |
1 ms to 512 ms |
| Power Consumption |
0.5A (no SFP) / 1.2A (2 SFP) / 1.5A max |
| Voltage Requirement |
5.5V DC |
| RIUP Support |
Yes |
| USB Interface |
Micro USB (CLI setup) |
| Firmware Upgrade |
WinLoader |
| Dimensions |
4 x 21.7 x 29.1 cm |
| Weight |
0.64 kg |
| Operating Temperature |
0°C to 60°C |
| System Compatibility |
PLC, PACSystems RX3i |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
Features
-
Supports up to 128 I/O devices across eight controllers.
-
Offers flexible topologies for scalable network design.
-
Enables diagnostics and setup via micro USB CLI.
-
Allows hot-swap operation without system disruption.
-
Provides LED indicators and manual restart button.
