Description
Overview
The IC695PBM300 PROFIBUS Master Module from GE Fanuc enables high-speed data exchange across industrial networks. Designed for the PACSystems™ RX3i platform, it supports up to 125 DP slaves and handles 3,584 bytes of input and output data.
This compact module operates at data rates from 9.6 kBit/s to 12 MBit/s and includes diagnostic counters, status tables, and LED indicators for real-time monitoring. The IC695PBM300 uses a 9-pin Sub-D connector and draws 440 mA at 3.3 VDC, ensuring stable performance in demanding environments.
Technical Specifications
| Specification |
Details |
| Model Number |
IC695PBM300 |
| Manufacturer |
GE |
| Module Type |
PROFIBUS Master Module |
| Product Range |
PACSystems™ RX3i |
| System Compatibility |
PLC |
| Communication Service |
Ethernet Router, PROFIBUS DP |
| Max DP Slaves |
125 |
| Data Capacity |
3,584 bytes input / 3,584 bytes output |
| Data Rates Supported |
9.6 kBit/s to 12 MBit/s |
| Connector Type |
9-pin Sub-D |
| Current Draw |
440 mA @ 3.3 VDC |
| LED Indicators |
PROFIBUS-compliant status LEDs |
| Dimensions (H×W×D) |
3.5 × 13.5 × 13.6 cm |
| Weight |
0.16 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Product Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| Discontinued Status |
Active |
| Operating Temperature |
0–60°C |
| Storage Temperature |
-40–85°C |
| Firmware Compatibility |
RX3i v2.9 or later |
| Software Requirement |
Machine Edition SP2 |
Key Features
-
Supports PROFIBUS DP-V1 Read, Write, and Alarm messaging.
-
Handles up to 125 slaves with 244 bytes per channel.
-
LED indicators simplify network and module diagnostics.
-
Compact 3.5cm height fits standard RX3i backplanes.
-
Firmware upgradeable via host controller using WinLoader.
