Product Description
The IC695CRU320 is a redundant CPU module for the PACSystems RX3i series, engineered to provide high availability and fault tolerance in critical industrial control systems. It supports dual-CPU redundancy configurations, ensuring uninterrupted operation for mission-critical applications in process control, power generation, and infrastructure automation.
This module features a 1 GHz Celeron M processor with 64 MB RAM and 64 MB non-volatile flash memory, capable of handling complex control programs across multiple racks. Built-in Ethernet (10/100 Mbps) and serial RS-232/RS-485 ports allow seamless integration with SCADA, HMI, and peer-to-peer networks. The IC695CRU320 is designed to occupy two RX3i slots and requires an external high-capacity battery (IC693ACC302) for memory backup during power loss.
Technical Specifications
| Feature |
Specification |
| Model |
IC695CRU320 |
| Manufacturer |
GE Fanuc / Emerson |
| Series |
PACSystems RX3i |
| Module Type |
Redundant CPU Module |
| Processor |
Celeron M, 1.0 GHz |
| RAM |
64 MB |
| Non-Volatile Flash |
64 MB |
| Redundancy Support |
Dual CPU redundant configuration (Primary/Backup) |
| I/O Capacity |
Supports thousands of I/O points across multiple racks |
| Communication Ports |
Ethernet 10/100 Mbps, RS-232, RS-485 |
| Protocols Supported |
SRTP, Modbus TCP/IP, Ethernet Global Data (EGD) |
| Programming Support |
Ladder Logic, Structured Text, C (Proficy Machine Edition) |
| Slot Requirement |
2 RX3i slots |
| Battery Requirement |
IC693ACC302 Lithium Smart Battery |
| Switchover Time |
Max 1 logic scan, min 3.133 ms |
| Max Program Blocks |
512 |
| Max Block Size |
128 KB |
| Operating Temperature |
0°C to +60°C |
| Dimensions |
Standard RX3i rack size |
| Weight |
2.06 lbs |
Key Features & Benefits
High Availability: Ensures continuous operation through dual CPU redundancy.
Reliable Processing: 1 GHz CPU provides fast execution for complex logic.
Generous Memory: 64 MB RAM and 64 MB flash accommodate extensive programs and data.
Flexible Connectivity: Ethernet and serial ports allow network and SCADA integration.
Industrial Reliability: Rugged design supports sustained operation in demanding environments.
Battery Backup: External high-capacity battery protects memory during power interruptions.
Applications
-
High-availability industrial automation systems
-
Critical process control in energy, water, and utilities
-
Redundant CPU configurations for fault-tolerant operations
-
Large-scale PACSystems RX3i multi-rack installations
FAQ
Q: Can the IC695CRU320 operate standalone?
A: It is designed for redundant CPU setups; a paired CPU module is required for full redundancy.
Q: What is the required battery for memory backup?
A: The module requires the IC693ACC302 Lithium Smart Battery for non-volatile memory retention.
Q: How fast is the switchover between redundant CPUs?
A: Maximum 1 logic scan, minimum 3.133 milliseconds.
Q: How many slots does this CPU occupy?
A: The IC695CRU320 occupies two slots in the RX3i rack.
