Description
Product Description
The IC695CMM002 is a high-performance Ethernet communications module for the PACSystems RX3i PLC series. It provides two independent 10/100 Mbps Ethernet ports, allowing reliable and high-speed data transfer between PLCs, supervisory systems, HMIs, and other networked devices.
Designed for industrial networking, the IC695CMM002 supports multiple protocols including SRTP (Server/Client), Modbus TCP/IP, and Ethernet Global Data (EGD). Each port is electrically isolated for noise immunity, ensuring stable operation in electrically challenging environments. This single-slot module integrates directly into RX3i racks and supports simultaneous communication with multiple devices, making it ideal for complex plant-wide networking architectures.
The module also supports serial communications with RS-232 or RS-485/422 interfaces, configurable for full- or half-duplex operation. Its rugged construction and proven reliability ensure continuous operation in demanding industrial applications.
Technical Specifications
| Feature |
Specification |
| Model |
IC695CMM002 |
| Manufacturer |
GE Fanuc / Emerson |
| Module Type |
Ethernet Communications Module |
| PLC Series |
PACSystems RX3i |
| Ethernet Ports |
2 x 10/100 Mbps, independent |
| Supported Protocols |
SRTP, Modbus TCP/IP, EGD |
| Serial Ports |
2 independent RS-232/RS-485/422 ports |
| Serial Communication |
Full or half duplex for RS-485/422, 7 or 8 data bits |
| Backplane Power |
0.7 A max @ 3.3 VDC, 0.115 A max @ 5 VDC |
| LEDs |
Module OK, Port Fault, Port Status |
| Slot Requirement |
Single-slot module |
| Isolation |
Electrical isolation between ports |
| Operating Temperature |
0°C to +60°C |
| Weight |
0.6 kg |
Key Features & Benefits
Dual Ethernet Ports: Offers redundancy and flexible network configurations.
Multi-Protocol Support: Seamlessly integrates with SCADA, HMIs, and third-party devices.
High-Speed Networking: Ensures rapid data exchange at 10/100 Mbps.
Scalable Architecture: Handles multiple simultaneous connections for large automation networks.
Industrial Reliability: Rugged design ensures dependable operation in demanding environments.
Applications
-
Plant-wide Ethernet networking for PACSystems RX3i PLCs
-
SCADA and HMI integration
-
Peer-to-peer PLC communication
-
Multi-device industrial networks requiring high-speed connectivity
FAQ
Q: How many Ethernet devices can connect simultaneously?
A: The module supports multiple simultaneous connections, limited by network architecture and CPU capacity.
Q: Are serial ports included in this module?
A: Yes, the IC695CMM002 features two serial ports supporting RS-232 or RS-485/422.
Q: What is required for installation?
A: It installs in a single-slot RX3i rack and is compatible with standard backplane power.
Q: Can it handle SCADA integration?
A: Yes, it supports SRTP, Modbus TCP/IP, and EGD for SCADA and supervisory communication.
