Description
Overview
The IC694MDL645 Voltage Input Module from GE Fanuc delivers fast and reliable signal acquisition for PACSystems™ RX3i PLCs. It features 16 input channels that support both positive and negative logic wiring, making it ideal for use with limit switches, sensors, and pushbuttons.
Each channel operates within a 0–30VDC input range and offers a 7ms typical response time. The IC694MDL645 includes 16 green LEDs for real-time input status and provides 250VAC continuous isolation for enhanced protection in industrial environments.
Technical Specifications
| Specification |
Details |
| Model Number |
IC694MDL645 |
| Manufacturer |
GE |
| Module Type |
Voltage Input Module |
| Product Range |
PACSystems™ RX3i |
| System Compatibility |
PLC, RX3i, RX7i (distributed) |
| Communication Service |
Ethernet Router |
| Input Channels |
16 |
| Input Voltage Range |
0–30 VDC |
| ON-State Voltage |
11.5–30 VDC |
| OFF-State Voltage |
0–5 VDC |
| Input Current |
Min 3.2 mA, Max 1.1 mA |
| Response Time |
7 ms per channel |
| Isolation Rating |
250 VAC continuous, 1500 VAC for 1 min |
| Dimensions (H×W×D) |
3.5 × 13.2 × 13.5 cm |
| Weight |
0.3 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Product Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| Discontinued Status |
Active |
Key Features
-
Supports 16 voltage input channels with positive and negative logic.
-
24VDC rated input with wide 0–30VDC operating range.
-
LED indicators provide real-time status for each channel.
-
250VAC isolation ensures protection from electrical interference.
-
Compatible with both local and distributed RX3i I/O configurations.
