Product Description
The IC694MDL350 is a high-density discrete input module designed for the GE Fanuc PACSystems RX3i PLC series. Optimized for reliable digital signal acquisition, this module supports 32 24 VDC positive logic inputs, allowing seamless connection to field devices such as pushbuttons, limit switches, and proximity sensors.
With opto-isolated inputs, the IC694MDL350 ensures stable performance in environments with electrical noise. The module connects via two 20-pin field connectors and fits directly into standard RX3i racks. It supports high-speed serial bus communication and requires firmware version 3.5 or later for operation. For installation, a compatible terminal block (IC694TBBX32 or IC693TBSX32) is required.
Built for continuous industrial use, this compact input module delivers reliable performance, flexibility in device integration, and efficient utilization of rack space. It is suitable for machine control, process monitoring, and medium-to-large automation systems.
Technical Specifications
| Feature |
Specification |
| Model |
IC694MDL350 |
| Manufacturer |
GE Fanuc / Emerson |
| Module Type |
Discrete Input Module |
| PLC Series |
PACSystems RX3i |
| Input Voltage |
24 VDC (Positive Logic) |
| Input Points |
32 |
| Logic Type |
Positive logic (current flows when input is ON) |
| Input Current |
Approx. 7 mA per point |
| Isolation |
Opto-isolated inputs for noise immunity |
| Response Time |
Typical 2 ms |
| Field Connections |
Two 20-pin connectors |
| Rack Compatibility |
Standard RX3i racks |
| Terminal Block Required |
IC694TBBX32 or IC693TBSX32 |
| Communication |
High-speed serial bus compatible |
| Firmware Requirement |
3.5 or later |
| Operating Temperature |
0°C to +60°C |
| Weight |
0.79 lbs |
Key Features & Benefits
High-Density Input: 32 points maximize module efficiency per rack.
Electrical Isolation: Opto-isolation ensures noise immunity and stable operation.
Versatile Integration: Compatible with multiple field devices including sensors and switches.
Compact and Compatible: Fits directly into RX3i racks with standard dimensions.
Reliable Operation: Engineered for continuous use in demanding automation environments.
Applications
-
Signal acquisition from field devices (switches, sensors, pushbuttons)
-
Machine control and process monitoring
-
Multi-rack RX3i PLC systems
-
Industrial installations requiring stable and isolated inputs
FAQ
Q: Is this module compatible with non-RX3i PLCs?
A: No, the IC694MDL350 is designed exclusively for PACSystems RX3i controllers.
Q: What terminal block is required for installation?
A: IC694TBBX32 or IC693TBSX32 is needed to connect field wiring.
Q: Can it handle AC input signals?
A: No, this module is designed for 24 VDC positive logic inputs only.
Q: Which firmware version is required?
A: Firmware 3.5 or higher is necessary for proper operation.
