Description
Product Overview
The IC693PWR321 High Capacity Power Supply Module from GE Fanuc’s Series 90-30 PLC family delivers stable power for both internal circuits and external modules. It installs in the leftmost slot of the baseplate and supports both AC and DC input sources. With a 30W output rating, this module provides three key voltages: 5VDC, 24VDC, and isolated 24VDC.
The IC693PWR321 includes built-in protection features such as short-circuit limiting, smart switch fusing, and an internal fuse. It supports RS-485 communication and is compatible with all Series 90-30 CPUs. Designed for Class 1, Division 2 environments, this module ensures reliable operation in demanding industrial settings.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693PWR321 |
| Module Type |
Power Supply Module |
| Product Series |
Series 90-30 |
| Manufacturer |
GE Fanuc |
| Dimensions |
3.5 × 13.2 × 13.5 cm |
| Weight |
0.36 kg |
| Input Voltage Range |
85–264 VAC / 100–300 VDC |
| Input Power |
90 VA (AC) / 50 W (DC) |
| Output Power |
30 W total |
| Output Voltages |
5VDC, 24VDC, isolated 24VDC |
| Max Output (5V/24V) |
15 W combined |
| Max Output (Isolated 24V) |
20 W |
| Inrush Current |
4 A peak for 250 ms |
| Communication Port |
RS-485 serial |
| Safety Certifications |
cULus, CE |
| Hazardous Location Rating |
Class 1, Division 2 |
| Protective Features |
Short-circuit limiting, smart fuse |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC693PWR321 supports both AC and DC inputs for flexible installation.
-
Three output voltages power internal logic and external modules.
-
Built-in diagnostics and protection ensure safe and stable operation.
-
RS-485 port enables communication with CPUs and peripheral devices.
-
Compact design fits into the leftmost slot of any Series 90-30 baseplate.
