Product Description
The IC693PCM300 is a high-performance programmable coprocessor module engineered for the GE Fanuc Series 90-30 PLC platform. It extends the computational capabilities of the standard CPU, enabling the execution of advanced calculations, custom algorithms, and data-intensive tasks without impacting main processor performance.
Powered by an Intel 80386EX processor at 16 MHz, the IC693PCM300 comes with 1 MB of RAM and 128 KB of non-volatile flash memory. It supports both C and BASIC programming languages, allowing engineers to implement user-defined applications, string processing, and complex math functions. The module features dual serial communication ports (RS-232 and RS-485) for flexible connectivity with terminals, CRTs, or external devices.
Designed for industrial reliability, this single-slot coprocessor fits directly into the Series 90-30 backplane and includes LED indicators for module status and operation feedback. Lithium battery support ensures data retention for RAM memory.
Technical Specifications
| Feature |
Specification |
| Model |
IC693PCM300 |
| Manufacturer |
GE Fanuc / Emerson |
| Series |
Series 90-30 PLC |
| Module Type |
Programmable Coprocessor Module (PCM) |
| Processor |
Intel 80386EX, 16 MHz |
| RAM Memory |
1 MB |
| Non-Volatile Memory |
128 KB flash |
| User Programming |
C, BASIC (MegaBasic) |
| Ports |
1 × RS-232, 1 × RS-485 |
| Supported Protocols |
Modbus RTU, GE Fanuc CCM |
| Slot Requirement |
Single-slot |
| Memory Backup |
Lithium battery for RAM retention |
| LED Indicators |
Yes, module status |
| Operating Temperature |
0°C to +60°C |
| Weight |
0.7 lbs |
Key Features & Benefits
Extended Processing Power: Offloads complex computations from the main CPU.
Custom Programming Support: Compatible with C and BASIC for tailored applications.
Dual Communication Ports: RS-232 and RS-485 enable device integration and data exchange.
Reliable and Rugged: Industrial-grade construction ensures continuous operation.
Enhanced PLC Functionality: Expands Series 90-30 systems with high-performance coprocessing.
Applications
-
Advanced data processing in process control systems
-
Custom algorithm execution in industrial PLC networks
-
High-speed string handling and mathematical computations
-
Integration with programming terminals or operator CRTs
FAQ
Q: Which PLC systems are compatible with IC693PCM300?
A: Exclusively designed for GE Fanuc Series 90-30 PLCs.
Q: What programming languages does it support?
A: Supports C and MegaBasic/BASIC for user-defined applications.
Q: Does it include memory backup?
A: Yes, a lithium battery preserves RAM memory during power loss.
Q: How many communication ports are available?
A: Two serial ports: RS-232 and RS-485 for flexible connectivity.
