Description
Overview
The IC693MDL930 Isolated Relay Output Module from GE Fanuc offers flexible and high-reliability switching for industrial automation systems. Designed for the Series 90-30 and PACSystems™ RX3i platforms, it features eight individually isolated normally open relay contacts.
Each channel supports a wide voltage range from 5–30VDC or 5–250VAC at 50/60Hz, with a 4A resistive load rating per point. The IC693MDL930 supports mixed-voltage operation across channels, making it ideal for controlling solenoids, motor starters, and indicator lamps in diverse environments.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693MDL930 |
| Manufacturer |
GE |
| Module Type |
Isolated Relay Output Module |
| Product Range |
PACSystems™ RX3i / Series 90-30 |
| System Compatibility |
PLC, RX3i, RX7i |
| Communication Service |
Ethernet Router |
| Output Channels |
8 individually isolated N.O. relays |
| Voltage Range |
5–30VDC / 5–250VAC @ 50/60Hz |
| Max Load per Point |
4 Amps (resistive) |
| Max Inrush Current |
5 Amps |
| Max Module Load (UL) |
20 Amps |
| Minimum Load |
10 mA |
| Isolation (Field–Logic) |
1500V |
| Isolation (Channel–Channel) |
500V |
| Power Consumption |
6 mA @ 5VDC, 70 mA @ 24V relay bus |
| Indicators |
8 output status LEDs |
| Dimensions (H×W×D) |
3.5 × 13.2 × 13.5 cm |
| Weight |
0.36 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Product Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
| Discontinued Status |
Active |
| Operating Temperature |
0–50°C |
Key Features
-
Eight isolated relay outputs support mixed-voltage operation across channels.
-
Handles both AC and DC loads with high inrush current tolerance.
-
LED indicators provide real-time output status visibility.
-
1500V field-to-logic and 500V channel-to-channel isolation ensure system safety.
-
Compact 3.5cm height fits standard RX3i and 90-30 backplanes.
