Description
Product Overview
The IC693MDL740 Positive Logic Output Module from GE Fanuc’s Series 90-30 PLC family delivers reliable current sourcing for industrial automation. It features 16 output points split into two groups of 8, each capable of handling up to 0.5 Amps. This module sources current from the positive power bus and supports loads such as relays, pilot lamps, buzzers, and contactors.
With rapid 2 ms ON/OFF response times and low off-state leakage current of 1 mA, the IC693MDL740 ensures efficient switching. It operates within a 12–24VDC range, tolerating voltage variations of +20% to –15%. Front-panel LEDs provide clear status indication for each output channel, enhancing diagnostics and monitoring.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693MDL740 |
| Module Type |
Positive Logic Output Module |
| Product Series |
Series 90-30 |
| Manufacturer |
GE Fanuc |
| Dimensions |
3.5 × 13.2 × 13.5 cm |
| Weight |
0.36 kg |
| Output Points |
16 (2 groups of 8) |
| Voltage Range |
12–24 VDC (+20% / –15%) |
| Max Load per Channel |
0.5 A |
| Max Inrush Current |
4.78 A for 10 ms |
| Output Voltage Drop |
≤ 1 VDC |
| Response Time |
2 ms ON / 2 ms OFF |
| Leakage Current (OFF) |
≤ 1 mA |
| LED Indicators |
16 (channel status) |
| Fusing |
External fuses recommended |
| Mounting Compatibility |
5-slot or 10-slot baseplate |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC693MDL740 supports 16 outputs with fast switching and low leakage current.
-
Each channel handles 0.5 Amps, suitable for various industrial loads.
-
LED indicators simplify diagnostics and real-time monitoring.
-
External fusing enhances protection and system safety.
-
Compatible with Series 90-30 baseplates for flexible installation.
