The IC693MDL645 from GE Fanuc is a positive logic output module designed for the Series 90-30 PLC platform. It delivers reliable 24 VDC output control across 16 channels, making it ideal for interfacing with binary field devices like relays, solenoids, and indicators.
This module features a compact 3.5×13×13.5 cm footprint and weighs 0.28 kg. The IC693MDL645 includes individual channel status LEDs and a Module OK indicator for real-time diagnostics and operational visibility.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693MDL645 |
| Module Type |
Positive Logic Output Module |
| Manufacturer |
General Electric (GE) |
| Series |
Series 90-30 |
| System |
PLC |
| Dimensions |
3.5 × 13 × 13.5 cm |
| Weight |
0.28 kg |
| Output Channels |
16 |
| Voltage Range |
0–30 VDC |
| Nominal Voltage |
24 VDC |
| On-State Voltage |
11.5–30 VDC |
| Off-State Voltage |
0–5 VDC |
| On-State Current |
≥3.2 mA |
| Off-State Current |
≤1.1 mA |
| Input Current |
7 mA at 24 VDC |
| Response Time |
1 ms On/Off |
| Power Consumption |
80 mA @ 5 VDC, 125 mA @ 24 VDC |
| Terminals |
20, with swing door |
| Indicators |
16 Channel LEDs, 1 Module OK LED |
| Color Coding |
Low-voltage identification |
| HS Code |
8537101190 |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Status |
Active |
Features & Performance
-
The IC693MDL645 supports fast switching for real-time control of field devices.
-
Its swing door design includes wiring references for simplified installation.
-
Each output channel includes an LED for clear operational feedback.
-
The module’s low-voltage color coding enhances safety and identification.
Applications & Compatibility
The IC693MDL645 integrates seamlessly into GE Fanuc Series 90-30 PLC systems. It supports a wide range of automation tasks, including machine control, process signaling, and discrete output management.
Compatible with push buttons, relays, and other 24 VDC actuators, the IC693MDL645 ensures dependable output performance in industrial environments.
