Product Overview
The IC693DSM302 Motion Mate Control Module from GE Fanuc’s Series 90-30 PLC family delivers precise motion control for industrial automation systems. Designed for use with GE digital servo motors, SL Series analog servos, and third-party analog servos, it offers flexible integration and high-speed performance.
Equipped with a digital signal processor, the IC693DSM302 supports dual-axis control and simplifies setup with minimal programming. It features an RS-232 serial port for external programming and firmware updates. The module processes motion blocks in under 5 milliseconds and supports wide-ranging motion parameters for positioning, velocity, and acceleration.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693DSM302 |
| Module Type |
Motion Mate Control Module |
| Product Series |
Series 90-30 |
| Manufacturer |
GE Fanuc |
| Dimensions |
3.5 × 13 × 13.7 cm |
| Weight |
0.34 kg |
| Control Type |
Dual-axis |
| Processor |
Integrated DSP |
| Serial Interface |
RS-232 |
| Positioning Range |
±8,388,607 units/sec |
| Velocity Range |
1–8,388,607 units/sec |
| Acceleration Range |
Up to 134,217,727 units/sec² |
| Block Processing Time |
< 5 milliseconds |
| Program Storage |
10 programs, 40 subroutines |
| Memory Type |
Non-volatile |
| Servo Compatibility |
GE digital, SL analog, third-party analog |
| Diagnostic Features |
Automatic data transfer, LED indicators |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC693DSM302 supports dual-axis motion control with minimal setup requirements.
-
RS-232 port enables external programming and firmware updates.
-
Fast block processing ensures responsive control in dynamic environments.
-
Non-volatile memory stores up to 10 programs and 40 subroutines.
-
Compatible with multiple servo types for flexible deployment.
