Description
Product Overview
The IC693CHS398 Expansion Baseplate from GE Fanuc’s Series 90-30 PLC family extends system capacity by adding five I/O module slots. It connects to the CPU baseplate via a 25-pin D-type female expansion port and supports up to 15 meters of cable length for additional baseplates.
This module requires a dedicated power supply mounted on the left slot and draws 170 mA at 5VDC. Unique slot dimensions prevent incorrect module installation, ensuring safe and reliable operation. The IC693CHS398 is incompatible with PCM, ADC, BEM, and CMM311 modules, making it ideal for specific industrial control setups.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693CHS398 |
| Module Type |
Expansion Baseplate |
| Product Series |
Series 90-30 |
| Manufacturer |
GE Fanuc |
| Dimensions |
3.5 × 13 × 13.5 cm |
| Weight |
0.18 kg |
| Slot Count |
5 I/O slots |
| Power Requirement |
170 mA @ 5VDC |
| Connector Type |
25-pin D-type female |
| Cable Length Support |
Up to 15 meters |
| Slot Compatibility |
Unique keyed slots |
| Power Supply Location |
Left-side slot |
| Expansion Port Location |
Right-side slot |
| Grounding Requirement |
Common ground with CPU baseplate |
| Incompatible Modules |
PCM, ADC, BEM, CMM311 |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC693CHS398 adds five expansion slots for Series 90-30 I/O modules.
-
A 25-pin connector ensures secure communication with the CPU baseplate.
-
Supports up to 15 meters of cable for extended baseplate configurations.
-
Unique slot dimensions prevent incorrect module placement.
-
Requires a dedicated power supply and common grounding for stable operation.
