Description
Product Description
The IC693CBL327 is a precision interconnect cable for GE Fanuc Series 90-30 PLCs, designed to establish reliable connections between modules and racks. Ideal for medium and large PLC systems, this cable ensures stable signal transmission and consistent communication across CPU, I/O, and specialty modules.
Constructed with factory-terminated 24-pin connectors and high-quality #24 AWG wires, the cable supports up to 1.2 A of current, with a right-angle design to optimize space within control panels. Its lightweight and durable construction withstands standard industrial environments, providing a compact, organized wiring solution. Compatible with multiple I/O modules and previously replaced by IC693CBL315, the IC693CBL327 supports plug-and-play installation for quick integration into Series 90-30 systems.
Technical Specifications
| Feature |
Specification |
| Model |
IC693CBL327 |
| Manufacturer |
GE Fanuc / Emerson |
| Series |
Series 90-30 PLC |
| Cable Type |
Interconnect / Module-to-Rack Cable |
| Length |
3 meters (approx. 10 feet) |
| Wire Gauge |
#24 AWG |
| Connector Type |
24-Pin Right-Angle D-Sub (PLC side) |
| Field Side Connector |
Flying leads |
| Current Rating |
1.2 Amps |
| Connector Depth |
2 inches (51 mm) |
| Shielding |
Unshielded |
| Compatible Modules |
IC694MDL752, IC694MDL753, 16/32-pt I/O modules |
| Replaced By |
IC693CBL315 |
| Weight |
0.9 lbs |
| Operating Temperature |
0°C to +60°C |
Key Features & Benefits
Reliable Signal Transfer: Maintains communication integrity between PLC racks and modules.
Factory-Terminated Connectors: Reduces installation errors and saves setup time.
Compact and Durable: Right-angle design and rugged construction minimize clutter and withstand industrial use.
Versatile Compatibility: Works with a range of Series 90-30 CPU and I/O modules.
Plug-and-Play Integration: Ready for immediate deployment in existing systems.
Applications
-
Series 90-30 PLC rack-to-rack connections
-
Module-to-module communication in multi-rack PLC systems
-
Medium-to-large process control installations
-
Replacing legacy IC693CBL315 cables for enhanced reliability
FAQ
Q: What modules are compatible with the IC693CBL327 cable?
A: Compatible with IC694MDL752, IC694MDL753, and standard 16- or 32-point I/O modules.
Q: How long is the cable?
A: The cable length is 3 meters (approximately 10 feet).
Q: Does the cable require shielding?
A: This cable is unshielded and designed for standard industrial environments; for high-noise applications, additional shielding may be needed.
Q: What is the connector orientation?
A: The PLC-side connector is a right-angle 24-pin D-Sub; the field side uses flying leads.
