Description
Product Overview
The General Electric IC693BEM321 belongs to the Fanuc 90-30 series and functions as an I/O Link Master Module. Engineers use this card to connect up to 16 slave modules, bridging them with the PLC CPU. Its compact design, measuring 3.6 × 13 × 13.5 cm and weighing 0.2 kg, ensures efficient installation and reliable operation in industrial automation systems.
Technical Specifications
| Parameter |
Specification |
| Model Number |
IC693BEM321 |
| Module Type |
Series I/O Link Master Module |
| Manufacturer |
GE Fanuc |
| Series |
90-30 / 90-70 |
| System |
PLC |
| Dimensions |
3.6 × 13 × 13.5 cm |
| Weight |
0.2 kg |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| Lead Time |
In Stock |
| MOQ |
1 |
| Status |
Active |
| Communication Service |
Ethernet router |
| Supported Modules |
Up to 16 slave modules |
| Max Inputs |
1024 digital inputs |
| Max Outputs |
1024 digital outputs |
| Power Supply |
5 VDC from baseplate |
| Communication Protocol |
RS-422, RS-485 |
| Connector |
20-pin Honda socket |
| Indicators |
3 status LEDs |
| Reset Function |
Reset button for faults and power link |
| Slot Capacity |
Up to 6 modules per baseplate |
Functional Highlights
The GE Fanuc IC693BEM321 supports RS-422 and RS-485 protocols, enabling robust communication across industrial networks. Engineers configure the module using handheld GE Fanuc programmers or proprietary software.
Three status LEDs provide clear operational feedback, while the reset button allows quick fault clearance and link control. The 20-pin Honda socket ensures reliable connectivity with field devices, while the module’s ability to handle 1024 inputs and outputs enhances system scalability.
Applications and Compatibility
The General Electric IC693BEM321 integrates seamlessly into GE Fanuc Series 90-30 and 90-70 PLC systems. Operators deploy this module in manufacturing, energy, and process industries where large-scale digital input and output management is required.
Its compatibility with multiple slave modules and support for up to six master modules per baseplate make the IC693BEM321 a versatile solution for complex automation networks. Engineers rely on its compact design, reliable communication protocols, and diagnostic features to maintain efficient industrial operations.
