Description
Overview
The IC693ALG391 from GE Fanuc is a precision analog current output module designed for Series 90-30 PLC systems. It features two independent output channels supporting both current and voltage signals, including 0–20 mA, 4–20 mA, 1–5 VDC, and 0–5 VDC.
This compact module measures 3.5×13×13.5cm and weighs only 0.34kg, making it ideal for space-constrained control panels. The IC693ALG391 ensures high-resolution output with 4µA for 4–20 mA and 1 mV for 1–5 VDC, enabling precise control of industrial actuators and instrumentation.
Technical Specifications
| Specification |
Details |
| Model Number |
IC693ALG391 |
| Module Type |
Analog Current Output Module |
| Manufacturer |
General Electric (GE) |
| Series |
Fanuc Series 90-30 |
| System |
PLC |
| Dimensions |
3.5 × 13 × 13.5 cm |
| Weight |
0.34 kg |
| Output Channels |
2 (Current/Voltage) |
| Signal Ranges |
0–20 mA, 4–20 mA, 1–5 VDC, 0–5 VDC |
| Resolution |
4µA, 5µA, 1 mV, 1.25 mV |
| Power Draw |
+5V @ 30 mA, +24V @ 215 mA |
| Communication |
Ethernet Router |
| HS Code |
8537101190 |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Status |
Active |
Features & Performance
-
The IC693ALG391 supports signal retransmission for panel meters and data loggers.
-
It interfaces easily with control valves, VFDs, and dampers.
-
The module draws 215 mA from +24V and 30 mA from +5V backplane.
-
Its rugged design ensures consistent performance in industrial environments.
Applications & Compatibility
The IC693ALG391 integrates seamlessly into GE Fanuc Series 90-30 PLC systems. It suits applications requiring precise analog control, including HVAC, process automation, and energy management.
Compatible with industrial devices like actuators, sensors, and monitoring equipment, the IC693ALG391 enhances system responsiveness and control accuracy.
