Description
Product Description
The IC693ACC307 is a dedicated rack filler module designed for the GE Fanuc Series 90-30 PLC systems. It serves as a mechanical accessory to occupy unused slots in the PLC rack, ensuring optimal airflow, protection against dust, and structural stability for installed modules.
This single-slot module includes integrated termination resistors for I/O bus applications, supporting expansion cables such as IC693CBL302 and IC693CBL314. Its compact design ensures quick installation and reliable performance within standard operating conditions. The IC693ACC307 is ideal for maintaining system integrity in medium- to large-scale automation setups.
Technical Specifications
| Parameter |
Description |
| Model |
IC693ACC307 |
| Manufacturer |
GE Fanuc / Emerson |
| Product Line |
Series 90-30 PLC |
| Module Type |
Rack Filler / Baseplate Terminator |
| Function |
Occupies unused module slots, provides mechanical protection and airflow management |
| Slot Requirement |
Single-slot |
| I/O Connector |
25-pin D-shell |
| Resistor Pack |
Integrated for I/O bus termination |
| Supported Expansion Cables |
IC693CBL302, IC693CBL314 |
| Expansion Cable Length |
Up to 15 meters (50 feet) |
| Dimensions |
Standard Series 90-30 rack size |
| Weight |
0.13 lbs |
| Operating Temperature |
0°C to +55°C (32°F to 131°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to 185°F) |
| Applications |
Packaging, material handling, food processing, PLC rack protection |
Key Features & Benefits
Mechanical Protection: Safeguards unused slots against dust, debris, and physical impact.
Airflow Management: Maintains proper cooling and ventilation for the PLC rack.
I/O Bus Termination: Built-in resistors ensure proper signal integrity for expansion cables.
Easy Installation: Plug-and-play design for single-slot integration.
Universal Compatibility: Works with all Series 90-30 PLC racks and associated modules.
Applications
-
Protecting empty slots in Series 90-30 PLC racks
-
Ensuring proper airflow for temperature management
-
Providing I/O bus termination for expansion cables
-
Use in packaging, material handling, and food processing automation setups
FAQ
Q: Can this module be used in other PLC series?
A: No, the IC693ACC307 is designed specifically for Series 90-30 PLCs.
Q: Does it include termination resistors?
A: Yes, integrated resistor pack ensures proper I/O bus termination.
Q: How many modules can fit per rack?
A: One filler per unused slot; total number depends on rack configuration.
Q: What cable types are supported?
A: Compatible with IC693CBL302 and IC693CBL314 expansion cables, up to 15 meters.
