Product Description
The IC690USB901 is a USB-to-SNP interface cable designed for GE Fanuc Series 90-30 and 90-70 PLCs. It enables modern PCs to connect with legacy PLC systems for programming, monitoring, and diagnostics. The cable supports long-distance communication and ensures compatibility with current Windows operating systems, providing engineers with a reliable bridge between USB-only devices and older GE PLC hardware.
Technical Specifications
| Specification |
Details |
| Model |
IC690USB901 |
| Part Number |
IC690USB901 |
| Product Type |
USB/SNP Programming Cable |
| Compatible PLC Series |
Series 90-30, 90-70, 90-20, 90-Micro |
| Cable Length |
3 meters |
| Interface |
USB to SNP (15-pin PLC port) |
| Max Communication Distance |
1.5 km at 19200 bps |
| Baud Rate |
300 bps – 1 Mbps, auto-adaptive |
| Data Format |
7/8 data bits, 1/2 stop bits, odd/even/no parity |
| Power Supply |
USB bus-powered (~50 mA) |
| Indicators |
Two-color LED for send/receive status |
| Operating Temperature |
-20°C to +75°C |
| USB Compliance |
USB V1.1 and USB CDC V1.1 standards |
| OS Compatibility |
Windows 2000, XP, 7, 10, 11 |
| Software Compatibility |
CIMPLICITY ME V5.0 and above |
| Cable Ends |
Molded USB and 15-pin male SNP connector |
| Weight |
2.0 lbs |
| PC Limitation |
Only one IC690USB901 per PC supported |
Key Features
-
Connects modern USB PCs with legacy GE Fanuc PLCs without additional drivers.
-
Supports long-distance communication up to 1.5 km for industrial applications.
-
LED indicators provide real-time data transmission status for diagnostics.
-
USB bus-powered plug-and-play design requires no external power supply.
-
Simulates traditional COM port for legacy software compatibility.
Applications
-
Online program edits and updates for Series 90-30/90-70 PLCs
-
Diagnostics and monitoring in process control systems
-
Maintenance of manufacturing and industrial machinery
-
Ideal for engineers maintaining legacy PLC installations
FAQ
Q: Can I use multiple IC690USB901 cables on the same PC?
A: No, only one cable per PC is supported to avoid communication conflicts.
Q: Which Windows versions are compatible?
A: Windows 2000, XP, 7, 10, and 11 are supported. Older systems such as WinNT4/95/98/Me/DOS are not supported.
Q: What is the maximum communication distance?
A: Up to 1.5 km at 19200 bps.
Q: Are there alternative cables for other GE Fanuc PLC series?
A: For Series 90-Micro or 90-20 PLCs, the IC690USB901 also provides full compatibility.
