Description

Product Overview

The GE Fanuc IC200UEO116 belongs to the VersaMax Micro PLC series and functions as a 16-point DC sink output expansion module. GE designs this unit for industrial automation tasks requiring compact dimensions, reliable switching, and efficient energy handling.

This module weighs only 0.26 kg and measures 9.4 × 9.3 × 7.5 cm, making it suitable for installations with limited space. Engineers benefit from isolated transistor outputs, which ensure safe separation between field and logic circuits.

Technical Specifications

Specification	Value
Model Number	IC200UEO116
Manufacturer	GE Fanuc
Product Range	VersaMax Micro PLC
Module Type	Expansion Output Module
Outputs	16 DC sink-type transistor
Weight	0.26 kg
Dimensions	9.4 × 9.3 × 7.5 cm
Origin	USA
HS Code	8537101190
Condition	Brand New
Lead Time	In Stock

Electrical Characteristics

• Voltage Range: 24VDC (-20% to +25%)

• Hold-up Time: 10 ms at 19.2VDC

• Input Current: 0.16A typical at 24VDC

• Power Rating: 4W

• Maximum Load: 0.5A per point, 3A per common

• Inrush Current: 1A maximum at 30VDC for 10 ms

• Switching Time: 0.5 ms ON/OFF

• Isolation Voltage: 1500V RMS between field and logic

• Minimum Switching Current: 1mA

Specifications

• Dimensions: 9.4 × 9.3 × 7.5 cm
• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
