Product Description
The IC200UDR064 from GE Fanuc Emerson VersaMax Micro series is a compact, all-in-one programmable logic controller designed for small to mid-sized automation systems. It integrates a 24 VDC power supply, discrete inputs, and relay outputs into a single housing, reducing panel space and simplifying installation.
Engineered for reliability in industrial environments, this micro PLC supports flexible input logic configurations and provides robust relay outputs capable of handling both DC and AC loads. The IC200UDR064 is well-suited for standalone control tasks or distributed automation architectures.
Key Technical Specifications
| Parameter |
Specification |
| Model |
IC200UDR064 |
| Manufacturer |
GE Fanuc Emerson |
| Product Series |
VersaMax Micro |
| Controller Type |
Micro PLC |
| Power Supply |
24 VDC |
| Total I/O Points |
64 Points |
| Digital Inputs |
40 x 24 VDC |
| Input Type |
Sink/Source (Positive & Negative Logic) |
| Digital Outputs |
24 Relay Outputs |
| Output Configuration |
Normally Open (NO) |
| Output Voltage Range |
Up to 240 VAC / 24 VDC |
| Output Current Rating |
2 A per point (Resistive Load) |
| Internal Current Consumption |
Approx. 400–450 mA (typical combined load) |
| Isolation |
Relay isolation per output channel |
| Mounting |
DIN Rail |
| Operating Temperature |
0°C to 55°C (typical industrial range) |
| Weight |
1.83 lbs |
Functional Features
-
Integrated design combining CPU, power supply, and I/O
-
Relay outputs suitable for mixed AC/DC load control
-
Flexible input logic selection (sink/source wiring)
-
Compact footprint for space-constrained panels
-
Reliable performance in continuous industrial operation
Typical Applications
-
Small machine automation systems
-
Packaging and conveyor control
-
HVAC and building automation
-
Pump and motor control panels
-
OEM equipment integration
FAQ
Q: Can the IC200UDR064 drive AC loads directly?
A: Yes, the relay outputs support switching up to 240 VAC, making them suitable for both AC and DC loads.
Q: Does this controller support expansion modules?
A: VersaMax Micro controllers have limited or no expansion capability compared to modular PLCs; for scalable systems, the VersaMax modular series is recommended.
Q: What type of input wiring is supported?
A: The unit supports both sourcing and sinking input configurations, allowing flexibility in field device integration.
