Product Description
The IC200UAL005 from GE Fanuc Emerson VersaMax Micro series is a compact multi-function PLC designed for hybrid control applications requiring both discrete and analog processing. It integrates control logic, I/O handling, and power management into a single microcontroller platform, reducing system complexity in small automation architectures.
This Micro 23-point controller combines digital, relay, and analog capabilities within one unit, supporting mixed-signal automation tasks such as machine sequencing, process monitoring, and signal conditioning. Its integrated design allows direct field wiring without external I/O modules, making it suitable for space-constrained control panels.
Key Technical Specifications
| Parameter |
Specification |
| Model |
IC200UAL005 |
| Manufacturer |
GE Fanuc Emerson |
| Product Series |
VersaMax Micro |
| Device Type |
Micro PLC Controller |
| Total I/O Capacity |
23 Points |
| Digital Inputs |
13 x 24 VDC |
| Analog Inputs |
2 Channels |
| Relay Outputs |
9 Channels |
| Analog Outputs |
1 Channel |
| Additional DC Output |
1 Channel |
| Input Voltage Range |
24 VDC nominal |
| Power Consumption |
Approx. 8 W |
| Input Current (typical) |
~0.3 A at 24 VDC |
| Inrush Current |
1 A max at 30 VDC |
| Inrush Duration |
10 ms |
| Mounting |
DIN Rail |
| Operating Temperature |
0°C to 55°C |
| Weight |
0.91 kg |
Functional Features
-
Integrated hybrid PLC with digital, relay, and analog I/O
-
Supports mixed-signal control without external expansion modules
-
Relay outputs suitable for AC/DC load switching
-
Analog channels for process feedback and control loops
-
Compact architecture optimized for small machine control
Application Scenarios
-
Compact OEM machinery control systems
-
Basic process control with analog feedback
-
Packaging and small production equipment
-
HVAC and environmental regulation systems
-
Multi-function standalone automation panels
FAQ
Q: Does the IC200UAL005 support both analog input and output control?
A: Yes, it includes 2 analog input channels and 1 analog output channel for basic process control applications.
Q: Can relay outputs handle AC loads?
A: Yes, the relay outputs are designed for switching AC or DC loads within rated specifications.
Q: Is this PLC expandable with additional modules?
A: The Micro series has limited expansion capability compared to modular VersaMax systems; it is intended for compact standalone use.
