Product Overview
The GE Fanuc IC200PBI001 belongs to the VersaMax series and functions as a Profibus Network Interface Unit (NIU). Engineers use this module to manage communication between PLC systems and I/O modules. Its compact design, measuring 8.9 × 12.7 × 3.2 cm and weighing 0.1 kg, ensures efficient installation and reliable operation in industrial automation environments.
Technical Specifications
| Parameter |
Specification |
| Model Number |
IC200PBI001 |
| Module Type |
Profibus Network Interface Module |
| Manufacturer |
GE Fanuc |
| Series |
VersaMax |
| System |
PLC |
| Dimensions |
8.9 × 12.7 × 3.2 cm |
| Weight |
0.1 kg |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| Lead Time |
In Stock |
| MOQ |
1 |
| Status |
Active |
| Communication Service |
Ethernet router |
| Power Consumption |
250 mA at 5V, 10 mA at 3.3V |
| Supported I/O Modules |
Up to 64 |
| Data Handling Capacity |
375 bytes of I/O data |
| Network Address Range |
1–125 (rotary switch selectable) |
| Data Rate |
9.6 Kbaud to 12 Mbaud (auto-detect) |
| Diagnostic Memory |
5 bytes |
| Indicators |
4 LEDs (Power, Health, Fault, Network) |
| Connector Type |
9-pin D-sub |
| Mounting |
DIN rail with latch mechanism |
| Station Support |
Up to 32 stations without repeaters |
Functional Highlights
The GE Fanuc IC200PBI001 supports Profibus communication with automatic data rate detection ranging from 9.6 Kbaud to 12 Mbaud. Engineers configure network addresses using a rotary switch, adjustable within the 1–125 range.
This module handles up to 375 bytes of I/O data and supports 64 I/O modules, expandable with additional racks. Four LED indicators display power, health, fault, and network status, while a Force LED enhances diagnostics.
The IC200PBI001 simplifies installation with DIN rail mounting and latch-based power connections. Its 9-pin D-sub connector ensures reliable communication across up to 32 stations without repeaters.
