Description
Product Description
The IC200MDL930 relay output module from GE Fanuc Emerson VersaMax I/O family is designed for flexible switching of AC and DC loads in distributed control systems. It provides eight independently isolated Form A relay outputs, supporting a wide range of industrial voltage levels for mixed-load applications.
Each output channel is built with electromechanical relay contacts, enabling direct interface with field devices such as solenoids, contactors, and indicator loads. The module is engineered for electrical robustness, offering reinforced isolation between channels and logic circuitry to improve system reliability in noisy environments.
Key Technical Specifications
| Parameter |
Specification |
| Model |
IC200MDL930 |
| Manufacturer |
GE Fanuc Emerson |
| Product Series |
VersaMax I/O |
| Module Type |
Relay Output Module |
| Number of Outputs |
8 Channels |
| Output Type |
Electromechanical Relay |
| Contact Form |
Form A (Normally Open) |
| Rated Load Voltage |
5–125 VDC / 120–240 VAC |
| Operating Voltage Range |
0–125 VDC / 0–265 VAC (47–63 Hz) |
| Max Load Current |
2.0 A (resistive load) |
| Minimum Load |
10 mA per point |
| Switching Frequency |
Up to 20 cycles/min |
| Response Time |
≤10 ms ON/OFF |
| Relay Construction |
Fixed coil, moving armature |
| Contact Material |
Silver alloy |
| Backplane Current |
Approx. 243 mA |
| Current Consumption |
Up to 435 mA max |
| Isolation |
250 VAC continuous, 1500 VAC for 1 min |
| Channel Isolation |
Individually isolated outputs |
| Temperature Range |
0°C to 30°C (operating) |
| Mounting |
DIN Rail / VersaMax Rack |
| Weight |
0.53 lbs |
Functional Features
-
8 independently isolated relay outputs for flexible load control
-
Supports AC and DC switching within a wide voltage range
-
High dielectric isolation for improved system protection
-
Fast switching response suitable for discrete control tasks
-
Silver alloy contacts for improved durability and conductivity
Application Scenarios
-
Industrial machine control panels
-
Motor starter and contactor switching
-
Lighting and alarm output control
-
Packaging and assembly automation systems
-
General-purpose relay interfacing in PLC systems
FAQ
Q: Can the IC200MDL930 switch both AC and DC loads?
A: Yes, it supports switching of AC and DC loads within the specified voltage and current limits.
Q: Are the outputs individually isolated?
A: Yes, each relay channel is electrically isolated to improve fault tolerance and system safety.
Q: Is this module suitable for inductive loads?
A: Yes, but external suppression devices are recommended for heavy inductive loads to extend relay life.
