Description
Product Overview
The IC200ACC415 from GE Fanuc is a dedicated communication interface module designed to bridge RS-232 serial devices with RS-485 multidrop networks. It is commonly used in VersaMax Nano and Micro PLC installations where extended communication distance and multi-device networking are required.
This converter enables stable signal translation between point-to-point RS-232 links and differential RS-485 bus structures, improving system flexibility in distributed control environments.
Functional Description
The module performs protocol-level electrical conversion without requiring configuration software. It supports transparent data transmission, allowing PLCs and field devices to communicate over extended cable distances while maintaining signal integrity in electrically noisy environments.
RS-485 output supports multi-drop topology, enabling multiple devices to share a single communication line.
Technical Specifications
| Parameter |
Specification |
| Model |
IC200ACC415 |
| Function |
RS-232 to RS-485 signal conversion |
| Supported Systems |
VersaMax Nano and Micro PLC platforms |
| Communication Type |
Asynchronous serial data transfer |
| Network Type |
RS-485 multi-drop bus support |
| Indicator |
LED status for TX/RX activity |
| Cable Requirement |
IC200CBL500 or equivalent interface cable |
| Power Supply |
Powered via connected PLC interface |
| Physical Weight |
0.05 lb |
| Mounting |
Inline accessory installation |
| Environmental Rating |
Industrial-grade rugged design |
Design Characteristics
The converter is built as a compact inline accessory, minimizing installation space within control cabinets. Its reinforced electrical design ensures stable operation under industrial noise conditions, including motor drives and switching power systems.
System Integration
The unit is fully compatible with VersaMax Nano and Micro PLC systems. It requires no additional configuration and operates transparently within existing serial communication structures. Installation is completed through direct connection using supported communication cables.
Typical Applications
This module is typically deployed in:
-
Multi-PLC communication networks
-
Distributed I/O architectures
-
Conveyor and material handling systems
-
Packaging line synchronization networks
-
Process monitoring systems requiring long-distance serial communication
Frequently Asked Questions
Q1: Does the module require external configuration?
No. It operates as a plug-and-play hardware converter without software setup.
Q2: Can it support multiple devices on one RS-485 line?
Yes. It enables RS-485 multi-drop communication for multiple nodes.
Q3: Is it compatible with all VersaMax PLCs?
It is designed for VersaMax Nano and Micro series systems.
Q4: What cable is required for installation?
The IC200CBL500 cable or equivalent is recommended for proper connection.
