Description
Product Overview
The DS200FSAAG2ABA Field Supply Gate Amplifier Board from GE Fanuc’s Mark V Series delivers reliable gate control for turbine automation systems. Designed for wind, steam, and gas turbines, this board enhances legacy Speedtronic control platforms with improved performance and flexible configuration.
It features six manually adjustable Berg-type jumpers (JP1–JP6), five standard jumpers, and four 2-pin connectors for multi-cable integration. A 10-pin connector supports high-density signal routing, while two fast-acting fuses rated at 30A and 60V protect the board from overloads. Factory-printed labels ensure accurate identification during installation and maintenance.
Technical Specifications
| Specification |
Details |
| Model Number |
DS200FSAAG2ABA |
| Module Type |
Field Supply Gate Amplifier Board |
| Product Series |
Mark V |
| Manufacturer |
GE Fanuc |
| Dimensions |
25.5 × 10.2 × 3.1 cm |
| Weight |
0.38 kg |
| Jumpers |
6 Berg-type + 5 standard |
| Connectors |
1 × 10-pin, 4 × 2-pin |
| Fuses |
2 (30A, 60V fast-acting) |
| Diagnostic Features |
Multiple test points |
| Mounting Compatibility |
Mark V turbine control racks |
| Communication Service |
Ethernet router |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
DCS |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The DS200FSAAG2ABA includes six configurable jumpers for hardware customization.
-
A 10-pin connector and four 2-pin ports support multi-cable integration.
-
Two onboard fuses protect against current surges and voltage spikes.
-
Factory labels simplify identification and ensure correct installation.
-
Test points allow fast diagnostics and system verification.
