Product Overview
The DS200ADGIH1AAA Interface Display Board from GE Fanuc’s Mark V Series supports legacy turbine control systems with robust signal management and diagnostic capabilities. Designed for steam and gas turbine assemblies, this board remains essential in Speedtronic-based configurations despite its legacy status.
It features a 40-pin connector, a 6-pin connector, and 60 configurable jumpers for flexible hardware setup. Multiple test points allow precise circuit diagnostics, while factory-printed labels ensure accurate identification during installation. The DS200ADGIH1AAA mounts securely using four screws aligned with cabinet rack slots and supports static-safe servicing procedures.
Technical Specifications
| Specification |
Details |
| Model Number |
DS200ADGIH1AAA |
| Module Type |
Display Board |
| Product Series |
Mark V |
| Manufacturer |
GE Fanuc |
| Dimensions |
28 × 21.9 × 2.2 cm |
| Weight |
0.54 kg |
| Connectors |
1 × 40-pin, 1 × 6-pin |
| Jumpers |
60 (manual configuration) |
| Test Points |
Multiple (for diagnostics) |
| Mounting Method |
4-screw rack alignment |
| Coating Type |
Conformal coating |
| Communication Service |
Ethernet router |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
DCS |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The DS200ADGIH1AAA includes 60 jumpers for flexible hardware configuration.
-
A 40-pin and 6-pin connector support multi-signal integration.
-
Test points enable precise diagnostics with calibrated equipment.
-
Factory labels simplify identification and reduce installation errors.
-
Static-safe handling ensures long-term reliability in turbine environments.
