The General Electric IC660BRD020 is a 16-point discrete source I/O block from the Genius I/O product series. This module is designed to provide reliable input/output control in industrial automation environments, specifically handling 24/48 Volts DC source signals. It acts as a critical interface between field devices and the controller, ensuring consistent signal processing and system integration within the Genius I/O architecture.
Features
- 16-point discrete source output circuitry.
- Supports a wide operating voltage range of 18 to 56 Volts DC (rated for 24 and 48 Volts DC).
- Designed for robust performance in industrial control systems.
- Maximum current draw of 300 milliamps.
- Compatible with the established Genius I/O communication network.
Technical Specifications
| Product Model |
IC660BRD020 |
| Manufacturer |
General Electric |
| Series |
Genius I/O |
| Circuit Type |
Source |
| Output Circuits |
16 |
| Operating Voltage |
18 to 56 VDC (24/48 VDC rated) |
| Max Current Draw |
300 mA |
| Max Ripple |
10% |
Installation Guidelines
- Ensure the system power is disconnected before installing or removing the I/O block to prevent electrical damage.
- Mount the module in a location that allows for adequate ventilation and cooling to maintain optimal operating temperatures.
- Verify that all field wiring is properly secured to the terminal blocks and that polarity is observed for all DC connections.
- Use shielded cables where necessary to minimize electromagnetic interference (EMI) in high-noise industrial environments.
- Handle the module using standard ESD (Electrostatic Discharge) precautions to protect sensitive internal components.
FAQ
What is the primary function of the IC660BRD020?
The IC660BRD020 is a 16-point discrete source I/O block used to interface 24/48 VDC field devices with a Genius I/O network.
What is the operating voltage range for this module?
The module operates within a range of 18 to 56 Volts DC, with specific ratings for 24 and 48 Volts DC applications.
Is this module compatible with other Genius I/O series components?
Yes, the IC660BRD020 is designed to function as part of the GE Genius I/O system, allowing for integration with other compatible blocks and controllers in the same series.
