Description
Product Overview
The GE DS3800NMEC1K1K Exciter Control Board belongs to the Mark IV series, designed for precise turbine regulation. Operators use its advanced analog I/O functions to manage gas and steam turbines efficiently. The module integrates EEPROMs, EPROMs, transistors, diodes, and capacitors, ensuring stable energy flow and reliable system performance.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS3800NMEC1K1K |
| Module Type |
Extended Analog I/O |
| Manufacturer |
GE |
| Product Range |
Multilin |
| Condition |
Brand New |
| Dimensions |
23.8 × 17.7 × 4 cm |
| Weight |
0.34 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System Compatibility |
DCS |
| Communication Service |
Ethernet Router |
| Status |
Active |
Functional Description
The DS3800NMEC1K1K features a variable resistor with a black knob and white arrow, enabling fine turbine adjustments from zero to one hundred. Thirty-five integrated circuits, including EEPROMs and EPROMs, store critical programming data, supporting flexible updates.
Ten half-circle black transistors amplify electrical signals, while diodes ensure one-way energy flow. Capacitors store energy within an electric field, stabilizing turbine operation. Nearly one hundred resistors regulate current, and a silver crystal oscillator provides precise timing. Six connection points allow seamless integration with surrounding circuit boards.
Applications and Compatibility
The GE DS3800NMEC1K1K Exciter Control Board supports DCS systems across industrial energy platforms. Engineers deploy it in gas turbine stations, steam turbine plants, and large-scale power generation facilities. Its compact 23.8x17.7x4cm design and 0.34kg weight simplify installation.
Compatibility with the Mark IV series ensures smooth integration into GE Speedtronic systems. The DS3800NMEC1K1K enhances turbine efficiency, stability, and synchronization, making it a vital component for modern energy infrastructures.
