Description
Overview
The DS3800HIOD1H1G digital I/O board from General Electric is a robust component in the Multilin DCS platform. It supports seamless drive system integration with modular connectors, retention levers, and jumper-based customization.
This board measures 22.9×18.7×1.8 cm and weighs 0.26 kg. The DS3800HIOD1H1G includes two 10-pin connectors and one 40-pin connector, all front-facing for easy access. Six onboard jumpers allow flexible configuration for various industrial control applications.
Technical Specifications
| Specification |
Details |
| Model Number |
DS3800HIOD1H1G |
| Module Type |
Digital I/O Board |
| Manufacturer |
General Electric (GE) |
| Series |
Multilin |
| System |
DCS |
| Dimensions |
22.9 × 18.7 × 1.8 cm |
| Weight |
0.26 kg |
| Connectors |
2 × 10-pin, 1 × 40-pin |
| Jumpers |
6 Customizable |
| Mounting Features |
Retention Levers, Modular Edge |
| Handling Precautions |
Static-Sensitive, Use Wrist Strap |
| Packaging |
Static-Protective Sealed Bag |
| Communication |
Ethernet Router |
| HS Code |
8537101190 |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Status |
Active |
Features & Performance
-
The DS3800HIOD1H1G supports secure installation with retention levers and modular edge connectors.
-
Its jumper configuration enables tailored signal routing and logic behavior.
-
Static-sensitive design requires proper grounding during handling and installation.
-
All connectors are positioned for front-panel access, simplifying cable management.
Applications & Compatibility
The DS3800HIOD1H1G integrates into GE Multilin DCS systems for digital signal processing in drive control environments. It suits applications requiring high-density I/O, customizable logic, and reliable signal isolation.
Compatible with GE drive systems, the DS3800HIOD1H1G enhances control panel flexibility and supports long-term system reliability when installed with proper ESD precautions.
