Description
Product Overview
The GE DS215UCIAG1AZZ05A UC2000 Core Motherboard from the Mark V Series supports Speedtronic turbine control systems. It integrates a microprocessor, PROM modules, and modular connectors, ensuring reliable performance in complex turbine automation environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS215UCIAG1AZZ05A |
| Manufacturer |
GE |
| Module Type |
UC2000 Core Motherboard |
| Dimensions |
28 × 21.42 × 2.5 cm |
| Weight |
0.6 kg |
| System |
DCS |
| Communication Service |
Ethernet router |
| Analog Output Channels |
Up to 12 |
| Output Current Range |
0–20 mA |
| Common Mode Voltage |
5 V DC |
| Max Lead Resistance |
15 Ω |
| Operating Temperature |
-30°C to +55°C |
| Indicators |
10 LEDs for health and error codes |
| Connectors |
Modular interface for daughter card |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Functional Highlights
The DS215UCIAG1AZZ05A includes ten diagnostic LEDs that display health and error codes through flashing sequences. Its modular connector supports daughter card integration, providing both signal and power connections for expanded functionality.
Design and Performance
GE engineered the DS215UCIAG1AZZ05A with robust construction and precise analog handling. It supports up to 12 channels with 0–20 mA output, while maintaining stability under wide temperature ranges. Its legacy design continues to deliver reliable turbine control.
Applications and Compatibility
The DS215UCIAG1AZZ05A UC2000 Core Motherboard suits gas and steam turbine systems requiring Speedtronic technology. It integrates seamlessly with Mark V platforms, supporting legacy system maintenance, repair, and replacement across industrial automation environments.
