GE DS200TCPAG1AJD Mark VI Turbine Control Processor
The GE DS200TCPAG1AJD, also cataloged as the DS200TCPA Turbine Control Processor, operates as a dedicated hardware component for sequencing, protection, and real-time process control within GE Mark VI Turbine Control System networks.
Suffix Breakdown & Model Matrix
DS200: Standard GE Mark VI circuit board form factor and product line designation.
TCPA: Base module functional designation for the Turbine Control Processor board.
G1: Group revision index indicating specific component bill-of-materials configuration.
Operating via backplane (+5 VDC / +-15 VDC supply rails)
System Architecture
Mark VI Turbine Control System
Communication Protocols
IONet Ethernet, RS-232, RS-485
Firmware Management
Field-upgradeable via GE Toolbox software
Slot Compatibility
GE Mark VI and Mark VIe VME rack assemblies
Backplane Bus & Deterministic Communication
The DS200TCPAG1AJD processes real-time fuel metering, valve actuation, and startup sequencing over a high-speed VME backplane bus structure. Deterministic networking across redundant processor nodes is maintained through high-velocity backplane bus communication velocity Licences and proprietary IONet Ethernet interfaces. The board features hardware-level I/O density scaling alongside firmware flash compatibility to preserve real-time control cycle execution across dual and triple modular redundancy (TMR) control topologies.
Frequently Asked Questions
Q: How is backplane power delivered to the DS200TCPAG1AJD during system operation?
A: Power is sourced directly from the Mark VI backplane assembly via dedicated pin allocations supplying +5 VDC and +-15 VDC regulated rails.
Q: Does replacing the DS200TCPAG1AJD require specialized cabinet reconfiguration?
A: No, the board functions as a direct drop-in replacement within compatible Mark VI VME rack slots without structural cabinet modifications.
Q: How is firmware maintained or updated on the processor card?
A: Firmware is flashed directly to on-board non-volatile memory using GE Toolbox software over the dedicated serial or Ethernet communication interface.
Field Installation Guidelines
ESD Protection: Wear a grounded wrist strap attached to the cabinet chassis ground point prior to handling the circuit board to prevent static discharge damage to sensitive semiconductor logic.
Power Isolation: Ensure backplane power supplies are fully de-energized or follow explicit Mark VI online rack swap procedures before inserting or removing the module from the VME chassis.
Physical Alignment: Align the top and bottom edge card guides carefully prior to sliding the board into the slot. Engage the card ejector handles completely to lock the backplane connectors into position.
Shielding and Grounding: Connect all external communication cables using shielded twisted pair cabling with 360-degree shield termination grounded to the chassis terminal bar. Maintain physical segregation between signal communication lines and high-voltage power conduits.
