GE DS200SLCCG3ADC LAN Communication Card

The GE DS200SLCCG3ADC, also cataloged as the DS200SLCCG3ADC LAN Communication Card, operates as a dedicated hardware component for LAN and serial communication processing within GE Mark V DS200 Speedtronic turbine control system platforms. The card manages interface signals, communication protocols, and diagnostic data exchange between control boards and external devices.

Hardware Specifications

Parameter	Specification
Model	DS200SLCCG3ADC
Brand	GE
Origin	United States
Weight	1 lb
Dimensions	Standard GE Mark V DS200 board form factor
Operating Temp	0 deg C to 60 deg C
Power Consumption	Not specified
Product Type	LAN Communication Card
Series	Mark V DS200
Functional Acronym	SLCC
Communication Ports	RS-232, RS-485, LAN interface
Supported Protocols	Modbus, Ethernet/IP depending on firmware
Processor	Embedded microcontroller
Memory	EPROM and RAM for communication logic
Indicators	Diagnostic LEDs for Power, TX, RX, Fault
Operating Voltage	24 VDC
Connector Interface	2PL connector with 9 pins
Mounting	Plug-in rack assembly

GE Mark V Communication Network Processing

The DS200SLCCG3ADC supports industrial control communication through LAN and serial interface management within GE Mark V DS200 architectures. The board processes communication signals between turbine control boards and connected external devices while providing diagnostic feedback through onboard status indicators.

For GE industrial control platforms, the communication design includes firmware flash compatibility management to maintain correct operation between hardware revision levels and Mark V control configurations. The G3ADC revision defines a specific hardware and firmware configuration for system integration.

Frequently Asked Questions

Q: What communication interfaces are supported by the DS200SLCCG3ADC?
A: The card supports LAN communication together with RS-232 and RS-485 serial interfaces for data exchange within compatible Mark V control configurations.

Q: Is the DS200SLCCG3ADC compatible with hot-swap installation?
A: Hot-swap capability is not specified for this communication card. Board replacement should be performed after power isolation according to GE Mark V maintenance procedures.

Q: What is the function of the 2PL connector on this board?
A: The 2PL connector provides the physical pin interface required for board-level connection within the GE Mark V DS200 rack assembly.

Field Installation Guidelines

Install the DS200SLCCG3ADC into the designated Mark V DS200 rack position with system power removed. Verify the connector alignment before seating the board and confirm that the card is fully engaged in the rack assembly.

Maintain separation between communication cables and high-current power wiring to reduce electromagnetic interference. Use shielded communication cables where required and connect cable shields according to industrial grounding practices.

After installation, verify diagnostic LED operation, communication link status, and firmware compatibility with the existing Mark V control configuration.
