The GE DS200SHVMG1AFE M-Frame Interface Board is a compact and reliable module designed for turbine control systems. Engineers use this board to manage signal connections efficiently, ensuring compatibility with legacy Mark V systems. Its lightweight build and robust construction make it suitable for demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS200SHVMG1AFE |
| Module Type |
M-Frame Interface Board |
| Manufacturer |
GE |
| Product Range |
Multilin |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.24 kg |
| Dimensions |
18.8 x 14.2 x 2 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
| Terminal Blocks |
Two 90-pin blocks (TB1, TB2) |
| Connectors |
Three 20-pin connectors |
| Signal Capacity |
Up to 180 wires |
Functional Description
The GE DS200SHVMG1AFE integrates two 90-pin terminal blocks, supporting up to 180 signal wires. Three 20-pin connectors enhance compatibility with turbine control applications, while specialized connectors eliminate the need for manual jumpers or hardware modifications. Engineers benefit from simplified installation and reliable integration into Mark V systems.
Its durable design ensures long-term performance in industrial environments. The GE DS200SHVMG1AFE provides efficient signal termination and supports automated control of wind, steam, and gas turbines, maintaining the legacy of GE’s Speedtronic technology.
Applications and Compatibility
The GE DS200SHVMG1AFE M-Frame Interface Board suits turbine control systems requiring precise signal management. It integrates seamlessly with Mark V systems and supports industrial automation projects involving wind, steam, and gas turbines. Professionals rely on the GE DS200SHVMG1AFE for maintaining legacy systems while ensuring operational reliability and efficiency.
