Description
Product Overview
The General Electric DS200SHVMG1A belongs to the Multilin product range and functions as an extended analog I/O board. GE engineers designed this module for the Mark V Turbine Control System, ensuring precise management of wind, steam, and gas turbine operations.
This board measures 23.8 × 17.7 × 4 cm and weighs 0.34 kg, making it compact yet robust for industrial environments. It integrates GE’s Speedtronic technology, providing reliable conversion of shunt signals into differential frequency outputs.
Technical Specifications
General Parameters
| Specification |
Value |
| Model Number |
DS200SHVMG1A |
| Manufacturer |
GE |
| Product Range |
Multilin |
| Module Type |
Extended Analog I/O Board |
| Weight |
0.34 kg |
| Dimensions |
23.8 × 17.7 × 4 cm |
| Origin |
USA |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Lead Time |
In Stock |
| System |
DCS |
Electrical and Functional Details
-
Processes shunt signals from -500 to +500 mV
-
Converts signals into 0–500 kHz differential frequency outputs
-
Utilizes DC voltage-controlled oscillator (VCO) circuits
-
Supports AC line currents with 10:1 transformer attenuation
-
Includes 17 onboard jumpers for configuration flexibility
-
Provides standardized I/O and Stab connectors
-
IA2PL-1 and IA2PL-2 connectors handle motor armature current shunt outputs
Functional Highlights
The DS200SHVMG1A interfaces directly with SCR bridges on M-frame drives and communicates with boards such as DCFB, SDCI, and PCCA. Engineers benefit from stable signal conversion, ensuring accurate turbine monitoring and control. Its compact design and standardized connectors simplify installation and integration.
Applications and Compatibility
The GE DS200SHVMG1A supports turbine automation systems across wind, steam, and gas applications. It remains compatible with Mark V series controllers, even though the series is considered obsolete. Industrial operators rely on this board for efficient signal processing and reliable turbine drive management.
Its compatibility with other GE boards, including DCFB and PCCA, allows engineers to expand control systems without sacrificing performance. This versatility makes the DS200SHVMG1A a valuable component in legacy turbine control solutions.
