GE DS200QTBAG1A RST Terminal Board

Configured for analog signal routing and termination in the Mark V SpeedTronic control system, the GE DS200QTBAG1A (DS200QTBAG1A RST Terminal Board) provides direct electrical interface functions. The board transfers field analog signals between external devices and drive control hardware, supports passive signal conditioning, and provides terminal access, jumper configuration, and diagnostic test points for cabinet-level integration.

Suffix Breakdown & Model Matrix

The available documentation identifies a single functional revision only. No official suffix matrix beyond the documented revision is specified.

Model Element	Description
DS200QTBAG1A	Complete catalog number
G1A	Functional Revision (Group 1, Revision A)
Assembly	Normal Assembly
Product Type	RST Terminal Board

Hardware Specifications

Parameter	Specification
Model	DS200QTBAG1A
Brand	GE General Electric
Origin	General Electric
Product Series	Mark V SpeedTronic
Product Type	RST Terminal Board
Functional Revision	G1A
Assembly Type	Normal Assembly
Signal Compatibility	0-10 V, +/-10 V, 4-20 mA, RTD, Thermocouple, Analog Outputs
Terminal Connections	Multi-point screw terminal blocks, 12-24 AWG conductors
Connection Interface	Ribbon cable headers to internal drive processors
Board Features	Passive signal conditioning, onboard jumpers, diagnostic test points
Mounting	Chassis or panel mounting using standoff screws
Operating Temp	0 deg C to 60 deg C
Storage Temp	-40 deg C to 85 deg C
Relative Humidity	5 % to 95 % non-condensing

Backplane Communication and Firmware Compatibility

The DS200QTBAG1A operates as an interface board within the Mark V SpeedTronic architecture through ribbon cable connections to associated drive control hardware such as the TC2000 controller. Signal processing on the board is passive, while jumper selections and wiring configurations adapt the interface for supported analog input and output types. Firmware execution remains within the connected control processors rather than on the termination board itself, making hardware revision compatibility an important consideration during replacement.

Frequently Asked Questions

Q: Does the DS200QTBAG1A support hot replacement while the control cabinet is energized?
A: Available documentation does not specify hot-swap capability. Replacement should be performed only after cabinet power has been removed according to plant maintenance procedures.

Q: Which field signal types can be terminated on this board?
A: The board supports analog interfaces including 0-10 V, +/-10 V, 4-20 mA loops, RTDs, thermocouples, potentiometer feedback, and analog output connections as specified by the associated control configuration.

Q: Are configuration changes performed through software or hardware?
A: Signal configuration is supported through onboard jumpers, terminal wiring arrangements, and connector selection. Control logic remains within the connected Mark V processors.

Field Installation Guidelines

• Verify the functional revision before replacing an existing board to maintain hardware compatibility.
• Label all field wiring before removal to preserve terminal assignments.
• Route analog signal cables separately from high-power motor conductors to reduce electrical interference.
• Terminate cable shields according to the control cabinet grounding practice and avoid unintended ground loops.
• Tighten terminal screws according to the equipment maintenance documentation and confirm conductor retention after installation.
• Inspect ribbon cable connectors for proper alignment before applying power, and verify all jumper positions against the project wiring drawings.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
