Description

GE DS200PCCAG6ACB Power Connect Board

Configured for DC power distribution and signal interconnection in GE Mark V Speedtronic turbine control platforms, the General Electric DS200PCCAG6ACB, also cataloged as the DS200PCCAG6A Power Connect Card, provides direct physical and electrical execution across drive power networks.

Hardware Specifications

Parameter	Specification
Model	DS200PCCAG6ACB
Brand	General Electric (GE)
Origin	USA
Weight	0.68 lbs
Dimensions	240 mm x 160 mm x 1.6 mm
Operating Temp	0 to 55 deg C
Power Consumption	24 VDC nominal input
Power Outputs	Regulated 5 VDC, 12 VDC, 24 VDC rails
Current Capacity	5 A total distributed
Circuit Protection	2 x 5 A input fuses
Diagnostic Interface	3 Status LEDs (PWR, 5V OK, 12V OK), 8 gold-plated test points
Mounting Type	4 x M4 screw standoffs

System Connectivity & Backplane Bus Integrity

The DS200PCCAG6ACB maintains backplane bus communication velocity and power delivery across Mark V drive architectures. Designed with multi-channel galvanic isolation and noise-suppression networks, the board mitigates cross-talk and high-frequency switching EMI emitted from high-power silicon-controlled rectifier (SCR) bridges. Integrated firmware flash compatibility across board revisions guarantees deterministic signal routing between central processing engines and peripheral gate drivers.

Frequently Asked Questions

Q: What action should be taken if the board loses power output while 24 VDC input remains active?

A: Inspect the two integrated 5 A input fuses on the PCB surface for open-circuit conditions using a digital multimeter. Verify that downstream loads on the 5 VDC, 12 VDC, and 24 VDC distribution lines do not present a direct short circuit to ground before replacing fuses.

Q: Can the DS200PCCAG6ACB board be hot-swapped while the Mark V control rack is powered on?

A: No. Hot-swapping the power connect card risks arcing across the 20-pin header contacts and damaging sensitive gate driver components. De-energize all primary 24 VDC feed lines and wait until all diagnostic LEDs fully discharge before performing maintenance.

Field Installation Guidelines

Ensure all system power feeds are locked out and tagged before handling the module. Standard electrostatic discharge (ESD) precautionary measures must be followed, including grounding wrist-straps attached to an unpainted metal chassis ground.

Mount the circuit board securely onto the designated enclosure plate using four M4 threaded metal standoffs, taking care not to warp the FR-4 substrate. Verify that all 20-pin terminal ribbon connectors are fully seated with locking clips engaged. Maintain separation between high-voltage power leads and low-voltage signal cabling within wire trays to prevent inductive noise coupling.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
