The GE DS200PCCAG1ADB Power Connect Card belongs to the Mark Vle turbine control system range. Engineers use this module to manage DC power connections between the drive and the SCR power bridge. Its compact design, lightweight build, and robust specifications make it suitable for demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS200PCCAG1ADB |
| Module Type |
Power Connect Card |
| Manufacturer |
GE |
| Product Range |
Mark Vle |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.32 kg |
| Dimensions |
28.8 x 7.2 x 3.8 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
Functional Description
The GE DS200PCCAG1ADB acts as a DC Power Connect Board, linking the drive with the SCR power bridge. Its rear-mounted connector simplifies installation and service, requiring only minor adjustments to adjacent boards. The card supports regenerative armature voltage scaling between 240 and 630 volts, ensuring compatibility with C and G frame units.
This module also accommodates AC and DC snubber styles, while supporting voltages above 480 V rms with separate bus transformers. The GE DS200PCCAG1ADB integrates an Intel Ultra Low Voltage Celeron 650 MHz microprocessor operating on QNX Neutrino OS. It handles analog input current at 240 V rms, DC bus voltage at 125 VDC, and auxiliary voltage of +15 VDC. Its operating temperature range spans 0 to 60°C, guaranteeing stable performance in industrial conditions.
Applications and Compatibility
The GE DS200PCCAG1ADB Power Connect Card works within Mark Vle turbine control systems and supports DCS environments requiring Ethernet router communication. It is widely applied in wind, steam, and gas turbine assemblies, offering reliable integration with GE Speedtronic technology. Compatibility with multiple power supply boards and transformers makes it versatile for industrial automation projects.
