GE DS200IMCPG1CCA I/O Motor Control Processor Board

The GE DS200IMCPG1CCA, also cataloged as the DS200IMCPG1CCA I/O Motor Control Processor Board, operates as a dedicated hardware component for motor control execution, I/O signal processing, and subsystem communication within the GE Mark V Speedtronic turbine control system.

Hardware Specifications

Parameter	Specification
Model	DS200IMCPG1CCA
Brand	GE
Origin	United States
Weight	0.4 kg
Operating Temp	0 deg C to +55 deg C
Product Type	I/O Motor Control Processor Board
Series	Mark V Speedtronic turbine control system
Power Supply	+5 VDC, +/-15 VDC via backplane
Processor Configuration	Motor Control Processor (MCP) and Co-Motor Processor (CMP)
Memory	PROM firmware storage and EEPROM configuration storage
Connectors	Mark V rack edge connectors and multi-pin I/O connectors
Diagnostics	LED indicators, RESET button, built-in test points
PCB Coating	Conformal coating

Deterministic Control and Communication Processing

The DS200IMCPG1CCA integrates processor resources for execution of motor control routines, analog and digital I/O signal handling, and communication exchange with other Mark V control boards. The board receives power through the rack backplane and uses onboard firmware storage for control logic configuration.

The GE industrial control architecture uses defined backplane communication paths for board-to-board data exchange. The IMCP module supports I/O density scaling through dedicated processor handling of motor-related signals and subsystem communication tasks.

Frequently Asked Questions

Q: What power interface does the DS200IMCPG1CCA use?
A: The board receives +5 VDC and +/-15 VDC power through the Mark V rack backplane connection.

Q: What processors are installed on the IMCP board?
A: The DS200IMCPG1CCA contains a Motor Control Processor (MCP) and a Co-Motor Processor (CMP) for control execution and additional processing functions.

Q: What diagnostic functions are available on this board?
A: The board provides LED status indicators, a RESET button, and built-in test points for troubleshooting processor and communication conditions.

Field Installation Guidelines

Install the DS200IMCPG1CCA in the designated Mark V rack slot and verify correct backplane alignment before insertion. Confirm that rack power is removed before replacing or servicing the board.

Use appropriate grounding practices for the control cabinet. Maintain separation between low-level signal wiring and high-current power conductors to reduce electrical interference. Verify connector seating, cable routing, and shielding termination before system startup.

Firmware compatibility should be checked against the existing Mark V controller configuration before board replacement or maintenance activity.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
