Description

Overview

The DS200FCGDH1B Gate Distribution and Status Board from GE is engineered for Mark V Control Systems. It manages SCR firing, feedback scaling, and diagnostic communication within a 6-pulse non-reversing bridge.

Technical Specifications

Specification	Detail
Manufacturer	GE
Part Number	DS200FCGDH1B
Product Series	Mark V Control System
Voltage Output	24 Vdc
Current Output	1A
Dimensions	240 mm × 160 mm × 30 mm
Weight	0.5 kg
Board Format	6U VME
Signal Interface	VME backplane
Mounting	VME rack with DS200DSPC
Layers	Six-layer PCB
Components	Surface-mounted devices (SMDs)

Key Features

• Decodes and distributes SCR cell gating signals across all bridge legs.

• Interfaces directly with DS200DSPC for signal input and diagnostic feedback.

• Scales bridge voltage, current, and frequency for real-time monitoring.

• Compact 6U VME format fits seamlessly into standard VME racks.

• Six-layer PCB with dual-sided SMDs ensures high-density performance.

Specifications

• Dimensions: 240 mm × 160 mm × 30 mm
• Brand: GE

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
