The GE DS200DTBBG1ABB Terminal Digital Connector Board belongs to the EX2100 series and plays a critical role in turbine automation. Measuring 2.1x18.6x26.3cm and weighing 0.22kg, this PCB integrates seamlessly into DCS environments. Manufactured in the USA, it supports Ethernet router communication and ensures reliable performance in demanding industrial applications.
Engineers designed the DS200DTBBG1ABB as a Contact Input Expansion Termination Module, extending connectivity and signal processing capabilities. Its robust construction includes rectifiers, diodes, capacitors, and integrated circuits, ensuring stable voltage management and long-term reliability.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS200DTBBG1ABB |
| Module Type |
Terminal Digital Connector Board |
| Manufacturer |
GE |
| Product Range |
EX2100 / Mark V |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.22 kg |
| Dimension |
2.1 x 18.6 x 26.3 cm |
| HS Code |
8537101190 |
| MOQ |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
Functional Description
The GE DS200DTBBG1ABB includes two terminal blocks supporting 95 signal wire connections. Three 50-pin connectors labeled JFF, JFG, and JFH provide additional integration options. Bayonet connectors and five jumpers allow flexible configuration, while mounting holes in each corner ensure secure installation.
Its design incorporates standardized Mark V Series components such as rectifiers, diodes, capacitors, and ICs. These elements regulate voltage, enhance stability, and maintain efficient system performance. The board’s durable build supports legacy turbine control systems, making it a reliable solution for industrial automation.
Applications and Compatibility
The DS200DTBBG1ABB Terminal Digital Connector Board suits industries requiring dependable DCS integration, including power generation, wind, steam, and gas turbine automation. It works seamlessly with GE EX2100 and Mark V systems, offering compatibility for upgrades and replacements. Professionals rely on the DS200DTBBG1ABB for enhanced connectivity, efficient signal processing, and reliable turbine control operations.
