Description

GE DS200DSPCH1A DSP Control Board

Configured for real-time feedback processing in GE Mark V / SPEEDTRONIC drive control platforms, the GE DS200DSPCH1A (DS200DSPCH1A DSP Control Board) provides direct digital signal execution for turbine control and motor drive algorithms.

Hardware Specifications

Parameter	Specification
Model	DS200DSPCH1A
Brand	General Electric (GE)
Origin	United States
Weight	1 lb
Dimensions	Shipping dimensions: 18 x 12 x 12 inches
Operating Temp	0 deg C to +60 deg C
Power Consumption	Not specified in available technical data
Product Series	Mark V / SPEEDTRONIC Drive Control Series
Board Type	Digital Signal Processor (DSP) Control Card
Core Processor	Onboard high-speed Digital Signal Processor
Primary Functions	Real-time feedback processing, motor control algorithms, signal filtering, speed sensing
System Compatibility	GE Mark V Speedtronic Turbine Control Systems, Mark V Drive Controllers
Connectors	Multi-pin ribbon connectors, edge headers, onboard test points
Configuration Hardware	DIP switches and jumpers for address and operating mode configuration
LEDs	Six status LEDs
Test Points	Four test points (TP1-TP4)
Pushbuttons	Two onboard pushbuttons

Firmware and DSP Control Processing

The DS200DSPCH1A performs dedicated digital computation within GE Mark V control architectures. The onboard DSP executes high-speed mathematical processing required for feedback loop calculations, signal conditioning, speed measurement, and drive control routines. The board operates as a processing layer between external feedback circuits, power conversion hardware, and the primary control system communication structure.

The DSPC hardware architecture supports deterministic execution of control algorithms where timing consistency is required for turbine and motor control applications. The board uses onboard switches, jumpers, and diagnostic test points for configuration verification and troubleshooting during commissioning or maintenance procedures.

Frequently Asked Questions

Q: What is the primary function of the GE DS200DSPCH1A board?
A: The DS200DSPCH1A is a Digital Signal Processor Control Board used for executing real-time signal processing, feedback calculations, and drive control algorithms within GE Mark V control systems.

Q: Does the DS200DSPCH1A support direct field sensor connection?
A: The board interfaces with system feedback hardware and control circuits through its board-level connectors and internal processing paths. Specific field wiring depends on the complete Mark V system configuration.

Q: Is the DS200DSPCH1A backward compatible with previous revisions?
A: The available technical data identifies this H1A functional revision as not backward compatible.

Field Installation Guidelines

Install the DS200DSPCH1A only in the designated GE Mark V or SPEEDTRONIC control rack position specified by the system hardware documentation.

Verify connector alignment before insertion and avoid applying mechanical force to edge connectors or ribbon interfaces. Maintain proper electrostatic discharge protection when handling the DSP control board.

Signal wiring associated with the board should be separated from high-current power conductors to reduce electrical interference. Cable shields should follow the grounding method defined for the complete control cabinet design. Confirm jumper and DIP switch settings before energizing the control system.

During replacement procedures, inspect mating connectors, rack contacts, and grounding points for contamination or mechanical damage before installing the replacement board.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
