Description
Overview
The GE DS200DMCBG1AJE DOS DUP Processor Board belongs to the EX2100 series and plays a vital role in turbine control systems. Measuring 28x21.4x3.3cm and weighing 0.64kg, this PCB integrates seamlessly into DCS environments. Manufactured in the USA, it supports Ethernet router communication and ensures reliable operation in demanding industrial applications.
Engineers designed the DS200DMCBG1AJE with multiple connectors, jumpers, and LEDs for diagnostics. Its revised design improves functionality compared to earlier versions, while standardized voltage suppression components guarantee stable performance.
Technical Specifications
| Parameter |
Value |
| Model Number |
DS200DMCBG1AJE |
| Module Type |
DOS DUP Processor Board |
| Manufacturer |
GE |
| Product Range |
EX2100 / Mark V |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Weight |
0.64 kg |
| Dimension |
28 x 21.4 x 3.3 cm |
| HS Code |
8537101190 |
| MOQ |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
Functional Description
The GE DS200DMCBG1AJE features three 26-pin connectors, one 40-pin connector, and 19 jumpers. Two LEDs labeled CR2 and CR12 provide real-time diagnostic feedback, helping operators monitor processing activity. Voltage suppression is managed by diodes, rectifiers, capacitors, and resistors, ensuring stable energy regulation.
This board represents a revised version of the original DS200DMCBG1, incorporating A, J, and E revisions for improved compatibility and performance. Its durable design and standardized components make it a reliable solution for turbine control systems, even though it is considered obsolete.
Applications and Compatibility
The DS200DMCBG1AJE DOS DUP Processor Board suits industries requiring dependable DCS integration, including wind, gas, and steam turbine control. It works seamlessly with GE Mark V and EX2100 systems, offering compatibility for upgrades and replacements. Professionals rely on the DS200DMCBG1AJE for efficient diagnostics, stable voltage management, and reliable turbine automation.
