Product Overview
The DS200ACNAG1ADD ARCNET Connection Card from GE is a vital communication interface for the Speedtronic Mark V Gas Turbine Control System. It enables robust data exchange between control processors and system modules using ARCNET protocol, ensuring fault-tolerant and redundant operation.
This card supports triple-redundant 16-bit microprocessor controllers and integrates seamlessly with the Mark V’s Software-Implemented Fault Tolerance (SIFT) architecture. It plays a key role in synchronizing turbine generators and managing critical control signals across the system.
Technical Specifications
| Specification |
Details |
| Manufacturer |
GE |
| Model |
DS200ACNAG1ADD |
| Ordering Code |
DS200ACNAG1ADD |
| Series |
Speedtronic Mark V |
| Origin |
United States |
| HS Code |
85389091 |
| Dimensions |
16 cm × 16 cm × 12 cm |
| Weight |
0.8 kg |
| Communication Type |
ARCNET |
| System Integration |
Triple-redundant control processors |
Installation & Configuration
Install the DS200ACNAG1ADD card into the designated slot within the Mark V control rack. Connect it to the system’s ARCNET network to enable real-time communication between processors and I/O modules. Ensure proper shielding and grounding for optimal signal integrity.
This card supports high-speed data transfer and redundancy, making it suitable for mission-critical turbine control applications.
Applications & Compatibility
The DS200ACNAG1ADD is designed for use in GE Speedtronic Mark V gas turbine control systems. It supports automated sequencing, fuel control, emissions management, and turbine protection.
Use this card in systems requiring reliable ARCNET communication, fault tolerance, and synchronized turbine operation. It is compatible with legacy and modern Mark V configurations.
