Description
Product Description
Overview
The MMS6823R from EPRO is a high-performance analog input module designed to capture and process up to 24 analog signals simultaneously. Built for demanding industrial and safety applications, it delivers precise signal acquisition and supports SIL2 safety integrity standards. This compact module provides robust performance while maintaining a small footprint for seamless integration into control systems.
Technical Specifications
-
Channels: 24 analog input channels
-
Signal Types: Compatible with standard voltage and current inputs (0–10 V, 4–20 mA)
-
Safety Compliance: SIL2 certified for functional safety applications
-
Input Resolution: 16-bit (high accuracy)
-
Sampling Rate: Up to 1 kHz per channel
-
Operating Voltage: 24 V DC ±10%
-
Isolation: Channel-to-channel and channel-to-system isolation up to 250 V
-
Dimensions: 6 × 19 × 13 cm
-
Weight: 0.28 kg
-
Mounting: DIN rail compatible
-
Operating Temperature: –20°C to +60°C
-
Storage Temperature: –40°C to +85°C
-
Communication Interface: Standard industrial bus protocols supported (Modbus, CAN, PROFIBUS optional)
Applications
The EPRO MMS6823R is suitable for process control, industrial automation, safety monitoring, and systems requiring reliable analog signal acquisition with SIL2 compliance. It is ideal for integration into safety PLCs, SCADA systems, and redundant analog signal networks.
Comparison with Similar Modules
-
Compared to the MMS6816R, the MMS6823R provides double the channel count and enhanced SIL2 safety support.
-
Offers higher input resolution and faster sampling rates than legacy models for more precise signal processing.
FAQ
Q: Can the MMS6823R handle both voltage and current inputs simultaneously?
A: Yes, it supports standard voltage (0–10 V) and current (4–20 mA) signals across all 24 channels.
Q: Is the module hot-swappable?
A: No, it requires system power-down for safe installation and removal.
