Description
Product Description
Overview
The Emerson WH5-2FF 1X00416H01 is a dual-output power supply module engineered for industrial control systems. Designed for reliability and flexibility, it delivers consistent 24 VDC or 25 VDC outputs while accommodating a wide AC input range. Integrated safety features ensure robust protection against short circuits, overvoltage, and undervoltage conditions.
Key Features
-
Dual-output power configuration for versatile applications
-
Wide input voltage range: 100–240 VAC, supporting 50–60 Hz operation
-
Output options include 24 VDC at 12 A or 24 VDC at 8 A
-
Maximum output power: 500 W
-
DIN-rail mountable for easy installation
-
Built-in protection against short circuits, overvoltage, and undervoltage
-
High reliability for continuous industrial operation
Technical Specifications
| Parameter |
Specification |
| Model Number |
WH5-2FF |
| Part Number |
1X00416H01 |
| Revision |
B |
| Input Voltage |
100–240 VAC |
| Input Current |
8 A |
| Output Voltage |
24 VDC (primary), 25 VDC (secondary) |
| Output Current |
24 VDC: 12 A or 8 A |
| Maximum Output Power |
500 W |
| Mounting |
DIN-Rail |
| Frequency |
50–60 Hz |
| Protections |
Short-Circuit, Overvoltage, Undervoltage |
Applications
Suitable for industrial control systems, automation equipment, and other critical applications requiring reliable DC power. The WH5-2FF 1X00416H01 ensures uninterrupted operation and simplifies integration with standard DIN-rail setups.
FAQ
Q: Can this power module handle voltage fluctuations?
A: Yes, it operates across a wide input range of 100–240 VAC, ensuring stable output under variable supply conditions.
Q: What mounting options are available?
A: Designed for standard DIN-rail installation for ease of setup and maintenance.
Q: What safety features are included?
A: Integrated short-circuit, overvoltage, and undervoltage protection safeguard connected equipment.
Similar Models Comparison
-
WH5-1FF: Single output, lower maximum power (240 W)
-
WH5-3FF: Dual output, higher power rating (600 W)
