Description

Product Overview

The Emerson VE4005S2B3 is an 8-channel analog output card engineered for the DeltaV S-series control system. Designed to deliver precise 4-20 mA signals with full HART protocol support, this module ensures reliable signal transmission and seamless communication with field devices. Its robust design enables continuous operation in demanding industrial process control environments, making it ideal for mission-critical applications.

Technical Specifications

Product Type: Analog Output Card
Model: VE4005S2B3
Manufacturer: Emerson
System Compatibility: DeltaV S-series DCS

Output Channels

• Number of Channels: 8 analog outputs

• Signal Type: 4-20 mA DC

• HART Support: Versions 5, 6, and 7

• Terminal Block: 16-pin mass termination

Electrical & Power

• Power Source: Standard DeltaV system power

• Power Consumption: Low-power design for reduced heat generation

Environmental Ratings

• Operating Temperature: -40°C to +70°C (-40°F to 158°F)

• Relative Humidity: 5% to 95%, non-condensing

• Shock Resistance: 10 g half-sine wave for 11 ms

• Vibration Resistance: 1 mm peak-to-peak (2–13.2 Hz), 0.7 g (13.2–150 Hz)

• Airborne Contaminant Resistance: ISA-S71.04-1985 Class G3

Mechanical & Mounting

• Form Factor: S-series plug-in card

• Mounting: Horizontal I/O carrier

• Conformal Coating: Protects against moisture, dust, and chemical contaminants

Key Features & Benefits

High Accuracy & Reliability

• Internal self-calibration ensures precise analog output across temperature and time.

• Supports advanced process control loops requiring high signal fidelity.

Redundancy & Availability

• Hot-swappable design allows replacement without shutting down other cards.

• Redundant pairs supported for critical loop protection.

HART Diagnostics

• Enables remote configuration and monitoring of smart transmitters.

• Detects open circuits, short circuits, and device status in real-time.

Rapid Integration

• Automatic identification by DeltaV software reduces commissioning time.

• Seamless plug-and-play operation within S-series carriers.

Application Scenarios

• Process variable control for flow, pressure, or temperature loops

• Integration with HART-enabled field transmitters

• Critical control systems requiring high reliability and minimal downtime

Technical Specifications Table

Feature	Specification
Number of Channels	8
Output Signal	4-20 mA DC
HART Protocol	v5, v6, v7
Terminal Block	16-pin mass termination
Power Supply	DeltaV standard system power
Form Factor	S-series horizontal I/O card
Isolation	Field-to-system galvanic isolation
Shock & Vibration	10 g (11 ms) shock, 1 mm/0.7 g vibration
Environmental Rating	ISA-S71.04-1985 Class G3
Operating Temperature	-40°C to +70°C

FAQ

Q: Can the VE4005S2B3 support HART diagnostics on all channels?
A: Yes, each channel supports HART communication for monitoring and device configuration.

Q: Is external power needed for the outputs?
A: No, the card operates on standard DeltaV system power.

Q: Can this card be replaced without shutting down the system?
A: Yes, the module is hot-swappable. Redundant configurations provide uninterrupted operation.

Q: Are there higher channel variants in the S-series?
A: Emerson offers additional S-series analog output cards with 16-channel options for larger systems.

Specifications

• Brand: EMERSON

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
