Description

Product Overview

The Emerson VE4001S2T1B2 is a high-performance isolated discrete input module designed for the DeltaV Series 2 control platform. It provides 8 fully optically isolated digital input channels, ensuring accurate and reliable data acquisition in demanding industrial environments. This module is suitable for applications including process control, safety system monitoring, and discrete signal detection.

Engineered for robustness, the module offers high-voltage isolation and consistent operation under extreme temperature and humidity conditions, making it ideal for both standard and harsh industrial installations.

Technical Specifications

Product Type: Discrete Input Module
Model: VE4001S2T1B2
Manufacturer: Emerson
System Compatibility: DeltaV M-series controllers

Input Channels

• Channels: 8 optically isolated digital inputs

• Nominal Input Voltage: 24 VDC

• Input Detection Threshold: ON ≥ 10 VDC, OFF ≤ 5 VDC

• Input Impedance: 5 mA at 24 VDC

• Optical Isolation: Tested at 1500 VDC

Power Requirements

• Local Bus Supply: 12 VDC, typical 75 mA, max 100 mA

• Field Circuit Power: Not required

• Optional Fuse Rating: 2.0 A

Operational Modes

• Supported Functions: Discrete input detection, pulse counting (<75 Hz)

Environmental Ratings

• Operating Temperature: -40°C to +70°C (-40°F to 158°F)

• Storage Temperature: -40°C to +85°C (-40°F to 185°F)

• Humidity Tolerance: 5–95%, non-condensing

Mechanical Properties

• Form Factor: Standard DeltaV I/O module size

• Mounting: Snap-in DIN rail compatible

Applications

• Industrial process monitoring

• Machine safety interlocks

• Discrete signal acquisition for automation systems

• Pulse counting for flow or event measurement

FAQ

Q: Can this module operate with field devices at different voltage levels?
A: It is designed for 24 VDC standard discrete signals. Signals outside the threshold range may not be reliably detected.

Q: What is the maximum pulse counting frequency?
A: The module supports discrete pulse counting up to 75 Hz.

Q: Is external power needed for the inputs?
A: No, field circuit power is not required; the module is powered through the DeltaV local bus.

Q: Are there similar modules with higher channel counts?
A: Emerson offers 16-channel and 32-channel discrete input modules in the VE4000S2 series for larger installations.

Specifications

• Brand: EMERSON

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
