Description

Overview

The Emerson SE3008 is a high-performance DeltaV™ SQ Controller designed for small to mid-sized process control applications. It functions as the central processing unit within the DeltaV™ S-series Distributed Control System (DCS), managing complex control strategies, coordinating field devices, and supporting advanced communication across the control network. This controller combines scalability, reliability, and ease of installation in a compact, rugged package.

Key Features

Scalable Performance

• Supports up to 750 Device Signal Tags (DSTs) and 3,200 SCADA tags.

• Suitable for unit-level control or smaller plant areas.

Redundancy Support

• 1:1 hot-standby redundancy ensures uninterrupted operation.

• Redundant controllers can be upgraded online to SX-class systems.

Electronic Marshalling Compatibility

• Fully integrates with CHARMs for flexible, distributed I/O deployment.

• Allows late I/O configuration without rewiring.

Plug-and-Play Commissioning

• Automatic I/O detection and self-addressing reduces setup time.

• Simplifies cabinet assembly with screw-less mounting design.

Environmental Robustness

• G3 conformal coating protects against corrosion and pollutants.

• Operates from -40°C to +70°C for extreme conditions.

Technical Specifications

Specification	Detail
User Memory	48 MB
Execution Cycle Rates	100 ms, 200 ms, 500 ms, configurable up to 60 s
Power Consumption	5 W typical / 7 W maximum
Input Voltage	24 VDC (via DeltaV system power supply)
Network Ports	Dual redundant 8-pin RJ-45 Ethernet
Environmental Protection	G3 Conformal Coating, -40°C to +70°C
Hazardous Area Ratings	ATEX Zone 2, IECEx, Class 1 Div 2
Mounting	Screw-less, high-density cabinet design

Applications

• Small and medium process units

• Modular plant sections

• Skid-mounted automation systems

• Areas requiring flexible, distributed I/O deployment

FAQ

Q: Can the SE3008 be upgraded to SX Controllers?
A: Yes, the controller can be replaced with an SX model without reconfiguring existing settings.

Q: What is the maximum number of I/O tags supported?
A: The SE3008 supports up to 750 Device Signal Tags and 3,200 SCADA tags.

Q: Is it suitable for harsh environments?
A: Yes, with G3 conformal coating and a wide -40°C to +70°C operating range, it can handle extreme conditions.

Q: Does it support redundancy?
A: Yes, it supports 1:1 hot-standby redundancy for critical applications.

Q: Which network interfaces are available?
A: Dual redundant 8-pin RJ-45 Ethernet ports ensure reliable communication.

Specifications

• Brand: Emerson

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
