Product Description
Overview
The Emerson EPR0PR6453/240-101 is a high-precision eddy-current proximity sensor engineered for non-contact measurement of shaft displacement and vibration in compact rotating machinery. Its compact design allows installation in confined spaces while maintaining high sensitivity for small-diameter shafts. This sensor is part of the PR6453 series and is commonly integrated with EPRO signal conditioners, including the CON021 and CON41, creating a reliable measurement chain for machinery diagnostics and protection systems.
Operating Principle
The sensor operates using eddy-current technology to monitor changes in the distance between the probe tip and a conductive rotating surface. These variations are converted into electrical signals proportional to shaft movement. When paired with a compatible signal conditioner, the system provides stable, linearized outputs suitable for condition monitoring platforms and automated control systems.
Technical Specifications
Measurement Characteristics
-
Measurement Method: Eddy-current, non-contact
-
Typical Measuring Range: 0.5 mm to 2.0 mm (dependent on configuration)
-
Frequency Response: 0.5 Hz to 20 kHz
-
Linearity: ≤ ±1% full scale (with matched converter)
-
Sensitivity: Optimized for high precision on small-diameter shafts
-
Minimum Shaft Diameter: 8 mm
-
Target Material: Conductive ferromagnetic metals (e.g., steel, nickel alloys)
Mechanical Design
-
Probe Head Diameter: 12.5 mm
-
Probe Length: 75–120 mm (version dependent)
-
Mounting: Threaded body for secure installation in limited spaces
-
Housing Material: Stainless steel
-
Sensor Tip: Industrial-grade wear-resistant material
-
Weight: 310 g
Environmental Performance
Applications
Ideal for compact rotating machinery, small motors, gearboxes, and other precision equipment where non-contact vibration and shaft displacement monitoring are required.
FAQ
Q: Can this sensor be used on non-ferromagnetic materials?
A: No, it is optimized for conductive ferromagnetic metals such as steel and nickel alloys.
Q: What signal conditioners are compatible with this sensor?
A: EPRO CON021 and CON41 signal conditioners are recommended for optimal linearization and measurement accuracy.
Q: Is it suitable for high-temperature environments?
A: Yes, the standard configuration supports operating temperatures from -40°C to +125°C.
